US Horizon H180GTGACB Adjustable Designer Series Glass To Glass Door Hinge 180 Degree Polished Chrome W/Brass Accents
Item #: H180GTGACB by U.S. Horizon Mfg., Inc.
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- Finished to Match Stainless Steel Allen Style Clamp Screws (Phillips Screws Available Upon Request)
- Available in a wide range of finishes will help you choose according to your style.
- All essential mounting hardware is included in the kit for your convenience
- Self-Centering 0° Return with reversible 5° Pin (Preset 5° and 45° Pins Also Available)
- Solid Forged Brass Construction
- It is a low maintenence functional hardware which is pocket-friendly too
- Precision Machined 300 Series Stainless Steel Components
- Dual Precision Wound Stainless Steel Return Springs
- Self-Closing from 25 Degrees
- Mouse Ear Design
- Designed for 3/8" and 1/2" Glass
- Wall Mount Hinges Include Finished to Match Stainless Steel Mounting Screws
- Allen Wrench Included
- Rated at 40lbs Per Hinge
Height
3-35/64
Finish
Polished Chrome W/Brass Accents
Material
Solid Forged Brass
Type
180 Degree
Screw Type
Matching Finish Stainless Steel Allen Style Clamp Screws
Mounting Style
Glass to Glass mount
Pack Size
1
Angle Degree
180 Degree
Designed For
3/8" and 1/2" (10 and 12 mm) Glass
Self-Closing
From 25 Degrees
Other Specifications
Maximum door weight: - 2-hinge - 80lbs (36kg) - 3-hinge - 120lbs (54kg) Maximum door width: - 2-hinge - 30" (762mm) - 3-hinge - 36" (914mm)
Hardware Includes
Allen Wrench
Installation Steps
1.Use 3 mm Hex Wrench (A) to loosen two screws (B) by turning one circle counter-clockwise. Then proceed with the adjustment. 2. Once you have aligned the door, re-tighten two screws.
