Hager 005971 296D Oil Rubbed Bronze
Item #: 005971 by THASE ENTERPRISE CO., LTD.
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Bolt Backset
1-1/2" (38.2 mm)
Bolt
Bolt head 1/2" (12.7 mm)
Slug
/trim-auxiliary/flush-bolts-coordinating-devices/296d
Strike Size
1-3/32" x 2-1/4" (28 mm x 57 mm)
Bolt Throw
3/4" (19 mm)
Material
Stainless steel with steel components
Product Overview
Notes:
- Non-handed
- ADA compliant
- Ideal for wood veneer doors
- Only two 1-5/32" diameter holes needed for easier door preparation
- Opening active door retracts top and bottom bolts
- Smaller profile adds stability to the door
- To only be used with non-beveled doors
Certifications:
- 3-hour fire rating for metal doors up to 4' wide x 8' tall (A Label rating)
- 1-1/2 hour fire rating on wood doors up to 4' wide x 8' tall (B Label rating)
- ANSI A156.3 Type #25
Finishes:
US10B, US32D
Notes:
- Non-handed
- ADA compliant
- Ideal for wood veneer doors
- Only two 1-5/32" diameter holes needed for easier door preparation
- Opening active door retracts top and bottom bolts
- Smaller profile adds stability to the door
- To only be used with non-beveled doors
