Hager 185909 3553 5" US3.APL.SCC.KD.ASA - Knob Entry (F109) Bright Brass

Item #: 185909 by Hager

UPC #: 798550859093

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Warranty

Lifetime

Door Thickness

1-3/8" - 1-3/4" (35mm - 45mm)

Rose Diameter

3" (76 mm)

Product Overview
3553 5" US3.APL.SCC.KD.ASA
SPECS :

Applications: Standard Duty Commercial

Backsets:

  • 2-3/4" (70mm)
  • 2-3/8" (60mm)

Certifications:

  • Meets BHMA Certified ANSI A156.2, Series 4000, Grade 2
  • UL/cUL Listed for all functions up to 3 hours for ""A"" label single doors
  • UL10C Positive Pressure Rated

Cylinders Cores:

  • Brass 6-pin - Keyed Different - Schlage C Keyway - standard
  • Cylinder drilled 6 pin , Keyed 5 pin - standard
  • Other keying options including 6 pin available from factory
  • Zero bit cylinders will be 6 pin keyed - standard
  • Interchangeable core, SFIC available

Exposed Trim: Wrought Brass or Stainless Steel

Features:

  • No exposed mounting screws
  • Non-handed

Functions: Entry (F109)

Keyway: Schlage C - Standard, other keyways optional

Knob Diameter: 2-1/4" (58mm)

Latchbolt Type: 1/2" Throw - Stainless Steel. Deadlocking latchbolt prevents manipulation when door is closed

Product Name: Grade 2 Cylindrical Knob

Strike Strikes:

  • 3935 - 1-1/4" x 4-7/8" (32 mm x 124 mm) ASA strike
  • Other strikes available
