Hager 047662 3880 ESC US3.WTN.LBM.ELEU - E Electrified Storeroom Bright Brass

Item #: 047662 by Hager

UPC #: 041359476627

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Warranty

One-Year on electrical componentsLifetime on mechanical components

Door Thickness

1-3/4" - 2-1/2" (45 mm - 64 mm)Please specify door thickness if greater than 1-3/4" (45 mm) or the door has an offset prep

Product Overview
3880 ESC US3.WTN.LBM.ELEU
SPECS :

Applications:

  • Heavy Duty Commercial
  • Industrial
  • Institutional

Backsets: 2-3/4" (70mm)

Certifications:

  • ADA Compliant ANSI A117.1 Accessibility Code
  • UL/cUL Listed for all functions up to 3 hours "A" label single doors
  • UL10C Positive Pressure Rated
  • BHMA Certified ANSI A156.13, Series 1000, Grade 1

CTC Length: 3-5/8" (92mm)

Cylinders Cores:

  • Brass - keyed different - Schlage C keyway - standard
  • Drilled 6-Pin, Keyed 5-Pin - standard
  • Other keying options, including keyed 6-pin, available from factory
  • Zero bit cylinders will be 6 pin keyed - standard
  • SFIC mortise housings available
  • SFIC uncombinated or combinated, brass 6- or 7-pin cores sold separately - standard
  • LFIC mortise housings available
  • LFIC zero bitted or combinated, brass 6-pin sold separately – standard. Schlage C keyway only.
  • Schlage "L" cam is used standard on Hager mortise locks

Electrical Specifications:

  • 3880ELEU / 3882ELEU
  • 12-24V AC/DC (250mA Max in rush, 10mA Max holding)
  • 125 VAC (3 AMP maximum current)
  • 30VDC (2 AMP maximum current)
  • Wire leads (22 AG current)
  • ELEU functions require 2 wires to power device
  • RX, LM, DPM switches require two wires per switch to monitor NO or NC position
  • All three switches provided with 3 wires so both NO and NC can be monitored
  • Quick Connect option available for ELEU, RX. LM and DPM

Escutcheons: 1-15/16" x 8" (50 mm x 203 mm)

Exposed Trim:

  • Cast Zinc -Standard
  • Cast Stainless Steel - Optional on Withnell (WTS) and William (WLS) only

Functions: Electrified Storeroom (F07)

Keyway: Schlage C - Standard, other keyways optional

Latchbolt Type: 3/4" (19 mm) throw with anti-friction tongue, all stainless steel

Lever Options: Archer, August, Charles, Johnston, Joshua, Louis, Warren, William and Withnell

Notes:

  • No exposed mounting screws
  • Concealed thru-bolts
  • Body is easily field reversible (shipped LHR by default)
  • Self adjusting case for beveled doors

Options:

  • Tactile Warning
  • Lead Lining
  • Quick Connect

Strike Strikes:

  • 1-1/4" x 4-7/8" (32 mm x 124 mm) ASA strike
  • Optional strikes available
