Helical Solutions 59171 Corner Radius End Mill: 5/8" Dia, 3/4" LOC, 0.0600" Radius, 3 Flute, Solid Carbide Zplus
Item #: 59171 by Helical Solutions
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Proprietary Coating Designation
Proprietary
Corner Radius Tolerance
-0.0020 to 0.0020 in
Shank Diameter Tolerance
h6
TIR Maximum (Decimal Inch)
0.0003
Overall Length Tolerance
-0.0620/0.0620 in
Mill Diameter Tolerance
h6
Secondary Workpiece Material Code
P
Variable Index
No
Single Or Double End
Single
Secondary Workpiece Material
Steel
Mill Diameter (Inch)
5/8
Mill Diameter (Decimal Inch)
0.6250
Material Removal Type
Roughing & Finishing
Helix Style
Medium
Flute Direction
Right Hand
Extended Reach
No
End Mill Material
Solid Carbide
Coating Classification
PVD
Centercutting
Yes
Vendor Drop Ship
N
UNSPSC Code
27112803
Shank Diameter (Inch)
5/8
Shank Diameter (Decimal Inch)
0.6250
Primary Workpiece Material Code
N
Primary Workpiece Material
Non-Ferrous Metal
Overall Length (Inch)
3
Overall Length (Decimal Inch)
3.0000
Length of Cut (Inch)
3/4
Length Of Cut (Decimal Inch - 4 Decimals)
0.7500
Corner Radius (Decimal Inch)
0.0600
Coolant Through
No
Coating/Finish
Zplus
Variable Helix
No
Series
H35AL-3
Cutting Direction
Right Hand
Length Type
Stub
Chipbreaker
No
Pitch
Coarse
Number of Flutes
3
End Type
Corner Radius
Shank Type
Straight-Cylindrical
Material Application
Aluminum
Flute Type
Spiral
For Use With
High Precision Toolholders
Product Overview
Corner Radius End Mill: 5/8" Dia, 3/4" LOC, 0.0600" Radius, 3 Flute, Solid Carbide 3" OAL, 5/8" Shank Dia, 35 deg Helix, Zplus Coated, Single End, Centercutting, Series H35AL-3
