Helical Solutions 59862 Corner Radius End Mill: 1/4" Dia, 1/2" LOC, 0.03" Radius, 5 Flutes, Solid Carbide Tplus
Item #: 59862 by Helical Solutions
See reviewsSee reviews
Use Code: SAVEBIG2025 for Extra 10% Off
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Shank Type
Straight-Cylindrical
Shank Diameter (Inch)
1/4
Variable Helix
No
Vendor Drop Ship
N
Length Of Cut (Decimal Inch - 4 Decimals)
0.5000
Overall Length (Inch)
2-1/2
TIR Maximum (Decimal Inch)
0.0005
Secondary Workpiece Material
Non-Ferrous Metal
For Use With
High Precision Toolholders
Mill Diameter (Inch)
1/4
Overall Length Tolerance
-0.0620/0.0620 in
Material Removal Type
Roughing & Finishing
Coating/Finish
Tplus
UNSPSC Code
27112803
Proprietary Coating Designation
Proprietary
Number of Flutes
5
Corner Radius Tolerance
-0.0020 to 0.0020 in
Length of Cut (Inch)
1/2
Chipbreaker
No
Secondary Workpiece Material Code
N
Mill Diameter (Decimal Inch)
0.2500
Primary Workpiece Material
Stainless Steel
End Type
Corner Radius
Corner Radius (Decimal Inch)
0.0300
Flute Type
Spiral
Extended Reach
No
Overall Length (Decimal Inch)
2.5000
Coolant Through
No
Mill Diameter Tolerance
-0.0020/0.0000 in
End Mill Material
Solid Carbide
Coating Classification
PVD
Flute Direction
Right Hand
Centercutting
Yes
Cutting Direction
Right Hand
Material Application
Stainless Steel
Shank Diameter (Decimal Inch)
0.2500
Pitch
Variable
Shank Diameter Tolerance
h6
Series
HEV-5
Single Or Double End
Single
Variable Index
Yes
Primary Workpiece Material Code
M
Product Overview
Corner Radius End Mill: 1/4" Dia, 1/2" LOC, 0.03" Radius, 5 Flutes, Solid Carbide 2-1/2" OAL, 1/4" Shank Dia, Tplus Coated, Single End, Centercutting
