Iscar 3328777 CNMG433-M3M IC830 Carbide Turning Insert TiAlN

Item #: 3328777 by Iscar

See reviewsSee reviews
See reviews summary
Use Code: SAVEBIG2025 for Extra 10% Off
In Stock

$27.77

/each
SAVE UP TO 2.78
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 30 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Standards

ISO 13399

Insert Thickness

4.76

Included Angle

80

Insert Material

Carbide

Series

Isoturn

Side Clearance

Negative

Coating Process

PVD

Coating/Finish

TiAlN

Corner Radius (Decimal Inch)

0.0470

Manufacturers Catalog Number

3328777

Primary Workpiece Material Code

P

UNSPSC Code

23242105

Vendor Drop Ship

N

Insert Length (Decimal Inch)

0.5080

Insert Thickness (Decimal Inch)

0.1870

Maximum Depth of Cut (Decimal Inch)

0.1970

Rake

Positive

Insert Hand

Right Hand

Inscribed Circle (Decimal Inch)

0.5000

Insert Length (mm)

12.90

Insert Shape

C - Diamond (Rhombic) 80-Deg

Clearance Code

N

Insert Shape Code

C

Chip Breaker

M3M

Insert Style

CNMG

Insert Size Code

433

Tolerance Code

M

Inscribed Circle (Inch)

1/2

Maximum Depth of Cut (mm)

5.00

Chip Breaker Operation

Roughing

Manufacturer Grade

IC830

ISO Size Code

120412

Grade Characteristics

Steel (P) - Moderate Wear-Resistance and Toughness to High Toughness

Length Range (Decimal Inch)

0.5000 - 0.6000

ANSI Size Code

433

Inscribed Circle (mm)

12.70

ISO Insert Code

CNMG120412

Corner Radius (mm)

1.20

Proprietary Coating Designation

SumoTec

Iso Code

CNMG 433-M3M

ANSI Insert Code

CNMG433

Product Overview
CNMG433-M3M IC830 Carbide Turning Insert TiAlN/AlTiN/TiN Finish, RH, 12.9mm Long, 12.7mm Inscribed Circle, 1.2mm Corner Radius, 4.76mm Thick, 80 degree Diamond
