Iscar 5569352 CNMG431-M3M IC807 Carbide Turning Insert TiAlN

Item #: 5569352 by Iscar

See reviewsSee reviews
See reviews summary
Use Code: SAVEBIG2025 for Extra 10% Off

$27.77

/each
SAVE UP TO 2.78
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Standards

ISO 13399

Insert Thickness

4.76

Included Angle

80.0

Insert Material

Solid Carbide

Series

Isoturn

Coating Process

PVD

Coating/Finish

TiAlN

Corner Radius (Decimal Inch)

0.0160

Manufacturers Catalog Number

5569352

Primary Workpiece Material

H

Primary Workpiece Material Code

H

Vendor Drop Ship

N

Insert Length (Decimal Inch)

0.5080

Insert Thickness (Decimal Inch)

0.1870

Maximum Depth of Cut (Decimal Inch)

0.1570

Rake

Positive

Secondary Workpiece Material

None

Insert Hand

Right Hand

Inscribed Circle (Decimal Inch)

0.5000

Insert Length (mm)

12.90

Insert Shape

Diamond

Clearance Code

N

Insert Shape Code

C

Chip Breaker

M3M

Insert Style

CNMG

Insert Size Code

431

Tolerance Code

M

Maximum Depth of Cut (mm)

4.00

Manufacturer Grade

IC807

Length Range (Decimal Inch)

0.5000 - 0.6000

Inscribed Circle (mm)

12.70

Corner Radius (mm)

0.40

Proprietary Coating Designation

SumoTec

Iso Code

CNMG 431-M3M

Product Overview
CNMG431-M3M IC807 Carbide Turning Insert TiAlN/TiN Finish, RH, 12.9mm Long, 12.7mm Inscribed Circle, 0.4mm Corner Radius, 4.76mm Thick, 80 degree Diamond
