Iscar 6405420 Grooving Insert: SCIR22 IC1008, Solid Carbide TiAlN

Item #: 6405420 by Iscar

See reviewsSee reviews
See reviews summary
In Stock

$70.21

/each
SAVE UP TO 7.02
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 30 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Overall Length (mm)

22.00

Standards

ISO 13399

Insert Material

Solid Carbide

Series

Swisscut

Coating Process

PVD

Coating/Finish

TiAlN

Manufacturers Catalog Number

SCIR 22-AR00-25K16

Material Grade

C1

Overall Length (Decimal Inch)

0.8661

Overall Width (Decimal Inch - 4 Decimals)

0.1181

Primary Workpiece Material

Universal

Primary Workpiece Material Code

H

Vendor Drop Ship

N

Insert Holding Method

Screw

Maximum Depth of Cut (Decimal Inch)

0.1496

Multi-use Tool

Yes

Overall Width (mm)

3.00

Single Or Double End

Single

Rake Angle

8.00

Full Radius

No

Insert Style

SCIR

Insert Size Code

22AR0025K16

Maximum Depth of Cut (mm)

3.80

Cutting Height (Decimal Inch)

0.2756

Manufacturer Grade

IC1008

Maximum Depth Of Cut Range (Decimal Inch)

0.1000 to 0.1500

Maximum Depth Of Cut Range (mm)

3.00 to 4.00

Iso Code

ISO 13399

Cutting Height (mm)

7.00

Product Overview
Grooving Insert: SCIR22 IC1008, Solid Carbide TiAlN & TiN Finish, 0.1496" Max Depth, Series Swisscut
