Milling Insert: SDEB080204, KCPK30, Solid Carbide TiN

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Kennametal 2210029 Milling Insert: SDEB080204, KCPK30, Solid Carbide TiN

Item #: 2210029 by Kennametal

See reviewsSee reviews
See reviews summary
In Stock

$39.72

/each
SAVE UP TO 3.97
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 177 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Material Application

Steel

Insert Material

Solid Carbide

Series

SDEB

Coating Process

CVD

Coating/Finish

TiN

Corner Radius (Decimal Inch)

0.0157

Manufacturers Catalog Number

SDEB080204

Material Grade

C1

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

Thickness (Decimal Inch - 4 Decimals)

0.0937

Thickness (Inch)

3/32

UNSPSC Code

23291601

Vendor Drop Ship

N

Coating Classification

CVD

Insert Holding Method

Screw

Insert Hand

Neutral

Inscribed Circle (Decimal Inch)

0.3272

Corner Radius (Inch)

1/64

Insert Shape

Square

Insert Style

SDEB

Insert Size Code

2.61.51

Hole Diameter (Decimal Inch)

0.1402

Relief Angle

15.00

Included Angle Degree

90

Inscribed Circle (Inch)

21/64

Hole Diameter (Mm) ( - 0 Decimals)

0.14

Manufacturer Grade

KCPK30

Inscribed Circle Range (Decimal Inch)

0.3000 to 0.3500

Thickness Range (Decimal Inch)

0.0000 to 0.1000

Corner Radius (mm)

0.40

Iso Code

SDEB080204

Product Overview
Milling Insert: SDEB080204, KCPK30, Solid Carbide TiN, TiCN, Al2O3 Coated, 0.0937" Thick
