Milling Insert: 3.90030SNGD, KCPK30, Solid Carbide - pack of 10

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Kennametal 2227129-XCP10 Milling Insert: 3.90030SNGD, KCPK30, Solid Carbide - pack of 10

Item #: 2227129-XCP10 by Kennametal

See reviewsSee reviews
See reviews summary
In Stock

$253.05

/package
SAVE UP TO 25.30
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 27 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Cutting Edge Style

Chamfered

Material Application

Steel

ANSI Code

ODG3125ISGD

Number of Cutting Edges

1

Standards

ANSI

Insert Material

Solid Carbide

Series

ODG

Coating Process

CVD

Coating/Finish

TiN

Corner Radius (Decimal Inch)

0.0079

Length (Decimal Inch - 4 Decimals)

0.4217

Manufacturers Catalog Number

3.90030SNGD

Material Grade

C1

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

Thickness (Decimal Inch - 4 Decimals)

0.1831

UNSPSC Code

23291601

Vendor Drop Ship

N

Width (Decimal Inch - 4 Decimals)

0.1201

Coating Classification

CVD

Insert Holding Method

Clamp

Maximum Depth of Cut (Decimal Inch)

0.4217

Multi-use Tool

Yes

Rake

Positive

Insert Hand

Neutral

Inscribed Circle (Decimal Inch)

0.1201

Insert Shape

Rectangle

Chip Breaker

GD

Insert Style

ODG

Insert Size Code

3125

Included Angle Degree

135

Maximum Depth of Cut (mm)

10.71

Manufacturer Grade

KCPK30

Inscribed Circle Range (Decimal Inch)

0.0000 to 0.2500

Single or Double Sided Insert

Single

Cutter Series Compatibility

A2

Length Range (Decimal Inch)

0.3200 to 0.4000

Thickness Range (Decimal Inch)

0.1750 to 0.1850

Corner Radius (mm)

0.20

Iso Code

3.90030SNGD

Product Overview
Milling Insert: 3.90030SNGD, KCPK30, Solid Carbide TiN, TiCN, Al2O3 Coated, 0.1831" Thick, 0.1201" Wide
