Milling Insert: WPMT080615ZZERGP, KC522M, Solid Carbide TiAlN

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Kennametal 2616310 Milling Insert: WPMT080615ZZERGP, KC522M, Solid Carbide TiAlN

Item #: 2616310 by Kennametal

See reviewsSee reviews
See reviews summary
In Stock

$53.61

/each
SAVE UP TO 5.36
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 218 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Cutting Edge Style

Honed

Material Application

Steel

ANSI Code

WPMT080615ZZERGP

Number of Cutting Edges

3

Standards

ANSI

Insert Material

Solid Carbide

Series

WPMT

Coating Process

PVD

Coating/Finish

TiAlN

Corner Radius (Decimal Inch)

0.0590

Length (Decimal Inch - 4 Decimals)

0.5866

Manufacturers Catalog Number

WPMT080615ZZERGP

Material Grade

C1

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

Thickness (Decimal Inch - 4 Decimals)

0.2500

Thickness (Inch)

1/4

UNSPSC Code

23291601

Vendor Drop Ship

N

Width (Decimal Inch - 4 Decimals)

0.5067

Coating Classification

PVD

Insert Holding Method

Screw

Multi-use Tool

Yes

Rake

Positive

Insert Hand

Right Hand

Inscribed Circle (Decimal Inch)

0.5067

Insert Shape

Trigon

Rake Angle

30

Chip Breaker

GP

Insert Style

WPMT

Insert Size Code

080615

Hole Diameter (Decimal Inch)

0.2165

Relief Angle

11.00

Included Angle Degree

60

Hole Diameter (Mm) ( - 0 Decimals)

0.22

Manufacturer Grade

KC522M

Inscribed Circle Range (Decimal Inch)

0.5000 to 0.5100

Single or Double Sided Insert

Single

Cutter Series Compatibility

KSWM

Length Range (Decimal Inch)

0.5000 to 0.6000

Thickness Range (Decimal Inch)

0.2500 to 0.3500

Corner Radius (mm)

1.50

Iso Code

WPMT080615ZZERGP

Product Overview
Milling Insert: WPMT080615ZZERGP, KC522M, Solid Carbide TiAlN Coated, 1/4" Thick
