Turning Insert: RNMG64RN KCP25, Solid Carbide - pack of 5

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Kennametal 3753523-XCP5 Turning Insert: RNMG64RN KCP25, Solid Carbide - pack of 5

Item #: 3753523-XCP5 by Kennametal

See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Cutting Edge Style

Chamfered

Number of Cutting Edges

8

Standards

ANSI

Included Angle

360

Insert Material

Carbide

Series

KENLOC

Side Clearance

Negative

Coating Process

MTCVD

Coating/Finish

TiCN

Corner Radius (Decimal Inch)

0.3750

Manufacturers Catalog Number

3753523

Material Grade

C2

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

UNSPSC Code

23242105

Vendor Drop Ship

N

Width (Decimal Inch - 4 Decimals)

0.7500

Width (Inch)

3/4

Coating Classification

CVD

Insert Holding Method

Clamp

Insert Length (Decimal Inch)

0.7500

Insert Thickness (Decimal Inch)

0.2500

Insert Thickness (Inch)

1/4

Maximum Depth of Cut (Decimal Inch)

0.0492

Multi-use Tool

Yes

Rake

Negative

Insert Hand

Neutral

Wiper Edge

No

Inscribed Circle (Decimal Inch)

0.7500

Corner Radius (Inch)

3/8

Insert Shape

R - Round

Clearance Code

N

Rake Angle

0

Full Radius

Yes

Insert Shape Code

R

Chip Breaker

RN

Insert Style

RNMG

Insert Size Code

64

Tolerance Code

M

Hole Diameter (Decimal Inch)

0.3125

Relief Angle

0

Inscribed Circle (Inch)

3/4

Multi-Use Application

Turning

Hole Diameter (Mm) ( - 0 Decimals)

7.93

Insert Length (Inch)

3/4

Maximum Depth of Cut (mm)

1.25

Chip Breaker Operation

Roughing

Manufacturer Grade

KCP25

ISO Size Code

190600

Grade Characteristics

Steel (P) - Moderate Wear-Resistance and Toughness

Length Range (Decimal Inch)

0.7000 - 10.0000

ANSI Size Code

64

ISO Insert Code

RNMG190600

Proprietary Coating Designation

Multilayer Coating

ANSI Insert Code

RNMG64

Product Overview
Turning Insert: RNMG64RN KCP25, Solid Carbide TiCN & Al2O3 Coated, 3/4" Inscribed Circle, Series KENLOC
