Boring Insert: TOGX14030414 CK3210, Cermet Uncoated

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Komet 6260154602 Boring Insert: TOGX14030414 CK3210, Cermet Uncoated

Item #: 6260154602 by Komet

See reviewsSee reviews
See reviews summary
Use Code: SAVEBIG2025 for Extra 10% Off

$54.75

/each
SAVE UP TO 5.47
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Corner Radius (mm)

0.41

Inscribed Circle (mm)

8.20

Manufacturer Grade

CK3210

Relief Angle

8

Insert Size Code

140304

Insert Style

TOGX

Rake Angle

14

Insert Shape

Triangle

Inscribed Circle (Decimal Inch)

0.3230

Insert Hand

Neutral

Rake

Positive

Insert Holding Method

Screw

Vendor Drop Ship

Y

Thickness (Decimal Inch - 4 Decimals)

0.1180

Length (Decimal Inch - 4 Decimals)

0.5360

Corner Radius (Decimal Inch)

0.0160

Coating/Finish

Uncoated

Coating Process

Uncoated

Series

TOGX

Insert Material

Cermet

Cutting Direction

Neutral

Thickness (mm)

3.00

Included Angle

60

Chipbreaker

14

Length (mm)

13.61

Shape

Triangle

Product Overview
Boring Insert: TOGX14030414 CK3210, Cermet Uncoated, 60 degree Triangle, 0.016" Corner Radius, 0.323" Inscribed Circle, 0.118" Thick, 8 degree Relief
