Manual Flush Bolt for Metal Doors Black Finish ( Must Be Sold In Multiples of 2 ea)

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Hager 282D19 Manual Flush Bolt for Metal Doors Black Finish ( Must Be Sold In Multiples of 2 ea)

Item #: 282D19 by Hager

See reviewsSee reviews
See reviews summary

$28.56

/each
SAVE UP TO 2.86
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • Manual Flush Bolt
  • For Use On Hollow Metal/Fire Rated Doors
  • Non-Handed
  • Bolt Head Rods Adjustable
  • Brass Faceplate With Steel Components

Series

280 Series

Finish

Matte Black

Strike

15/16" x 2-1/4"

Design

Manual

Finish Description

Black

Product Type

Door Accessory

Door Thickness

N/A

Product Material

Brass Faceplate with Steel Components

Bolt Diameter

1/2 Inch

Strike Size

1" x 2-9/32" x 1/16"

Bolt Backset

3/4 Inch

Manufacturer Parent

Hager Companies

Body Size

1-1/32" x 6-25/32" x 1/8"

Function

Flush Bolt

Sub-Series

DTA_Flush_Bolts_and_Coordinators_hager_03

ADA Compliant

No

Application

Hollow Metal/Fire Rated Doors

Box Dimensions (L x W x H)

8x11.5x24

Function Family

Door Accessory

Standards

Meets ANSI 156.16 for L04251; 3 hrs Fire Rating

Rod Length

12 Inch

Features

282S Strike Plate Bag and 282P Bolt Head Available; Bolt Heads are Adjustable; Bolt Head, If Required May be Ordered as Part 282P

Color Code

622/US19/MTBK

Guide Size

1-1/32" x 2-1/16"

Bolt Throw

3/4 Inch

Included Components

(8) #8 X 3/4" Combo Screws; (8) #8 X 1-1/2" Combo Screws

Finish Family

Black

Dimension

1" x 6-3/4" Faceplate

No of inners

1

Depth

1-1/4"

Finish code

US19

Material

Brass with Steel Components

Manufacturer Warranty

Limited Lifetime Warranty and 1 Year Finish Warranty

Hazardous Material

No

Product Overview
282DManual Flush BoltFeatures:
  • Sold and priced in increments of two
  • 282S strike plate bag and 282P bolt head available
  • For use on hollow metal/fire rated doors
  • Non-handed
  • Bolt heads are adjustable
  • 282R optional rod lengths available: 18" (457 mm), 25" (635 mm), and 30" (762 mm) for a nominal charge
  • Bolt head, if required, may be ordered as part 282P
Specifications: Rod Length:
  • 12" (305 mm) from center of face to corner of door
Optional Rod Length:
  • 18" (457 mm). 25" (636 mm). 30" (762 mm). Specify 282R.
Material:
  • Brass faceplate with steel components
Faceplate:
  • 1" x 6 3/4" (25 mm x 171 mm)
Bolt:
  • Backset: 3/4" (19 mm)
Bolt Throw:
  • 3/4" (19 mm)
Fasteners:
  • Eight #8 x 3/4" combo screws, Eight #8 x 1 1/2" combo screws
Certifications:
  • Three-hour fire rating for metal doors up to 4' wide by 10' tall
  • Meets ANSI 156.16 for L04251
Finishes:
  • US10B - Oil Rubbed Dark Bronze
  • US15 - Satin Nickel
  • US19 - Matte Black
  • US26 - Bright Polished Chrome
  • US3 - Bright Polished Brass
