Mustang 54 XP 17ASFAC3066 Zero Turn Rider, 24 hp, 725 cc Engine Displacement, 2-Cylinder, 54 in W Cutting

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Troy-Bilt 17ASFAC3A66 Mustang 54 XP 17ASFAC3066 Zero Turn Rider, 24 hp, 725 cc Engine Displacement, 2-Cylinder, 54 in W Cutting

Item #: 17ASFAC3A66 by MTD Products

UPC #: 43033597666

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • Kohler 7000 Series engine delivers premium power and performance
  • Built in America with US and global parts since 1937
  • Large 54 in deck mows faster and more efficiently
  • Heavy-duty, full length, fully welded, 2 in tubular frame is designed to absorb impact, provide maximum stability and covered by a limited lifetime warranty
  • Ride in more comfort and reduced vibration with the high-back seat and foam grip steering controls
  • Large 3.5 gal fuel tank means less stopping for fill ups when mowing for extended periods of time

Height

35.50

Length

84.00

Width

60.00

Number of Blades

3

CARB Compliant

N

Commercial/Residential

Residential

Cutting Options

Side Discharge

Deck Material

Steel

Fuel Tank Capacity (gallons)

3.5

Maximum Forward Speed (mph)

7

Engine Brand

Kohler

Hazardous Material

Yes

Recommended Oil Type

10W-30

Speed Control

Variable

Cutting Width (in.)

54

Engine Displacement (cc)

725

Front Wheel Size (in.)

11

Lawn Mower Type

Riding Mower

Maximum Cutting Height (in.)

4.5

Minimum Cutting Height (in.)

1

Mower Start Type

Key Start

Recommended Terrain

Flat

Size of Yard

2-3 Acres

Horsepower (hp)

24

Lawn Tractor Transmission Type

Hydrostatic-Enclosed Dual

Maximum Reverse Speed (mph)

2

Mower Deck Construction

Stamped

Mower Deck Width (in.)

54

Number of Cylinders

2

Number of Deck Wheels

3

Oil Capacity (oz.)

64

Rear Wheel Size (in.)

20

Self Propelled Mower Drive Type

Rear-Wheel Drive (RWD)

Country Origin Code

US

Start Type

Electric

Turning Radius

0 deg

Air Filter

Dual Element

Engine Displacement

725 cc

Engine Type

Kohler Pro 7000 Series

Fuel Tank Capacity

3.5 gal

Maximum Forward Speed

7.5 mph

Maximum Reverse Speed

3.5 mph

Steering Type

Lap Bar

Transmission Type

Hydro-Gear ZT 2800

Blade Engagement Type (PTO)

Electric

HP Rating

24 hp

Nomenclature

17ASFAC3A66 MWER ZT XP HYD54IN

Engine Specifications

2 qt Engine Oil Capacity Choke-A-Matic Choke Fully Pressurized Lubrication

Number of Deck/Anti-Scalp Wheels

3

Dimensions

80 in L x 64-1/2 in W x 43-1/2 in H

Warranty

3 Year Limited Residential, Limited Lifetime Frame/Deck Shell

Product Overview
MOWER ZERO TURN XP HYDRO54IN
Specifications:

Warranty: 3 Year Limited Residential, Limited Lifetime Frame/Deck Shell

Engine Specifications: 2 qt Engine Oil Capacity Choke-A-Matic Choke Fully Pressurized Lubrication

Includes: Deck Wash Rear Tow Hitch

Premium power, performance and reliable starting every time with Kohler 7000 Pro Series engine. The large 54 in reinforced flat top deck on the Mustang 54 XP mows large area faster and moves easily across the yard with the support of two deck wheels and a front roller to smooth over bumps.
