Schlage Commercial ND70BD SPA 626 ND Series Classroom Small Format Less Core Sparta with 13-247 Latch 10-025 Strike Satin Chrome Finish
Item #: ND70BD SPA 626 by Schlage Commercial
Brand: Schlage Commercial
UPC #: 840067604441
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Classroom, Outside Lever Locked and Unlocked by Key, Inside Lever Always Unlocked for Immediate Egress
- ANSI/BHMA Certified A156.2-2011
- Handing: All ND-Series lever locksets are non-handed.
- 1-5/8" to 2-1/8" Door Range
- Door Thickness: 1 5/8” to 2 1/8” (41mm–54mm) standard including Vandlgard® functions. 1 3/4” - 2” for function ND85. See accessories for spacers required for 1 3/8” doors.
- Commercial Grade 1
- UL Listed for 3 Hour Fire Door
- Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5” (60 mm, 95 mm, 127 mm) optional.
- Faceplate: Brass, bronze or stainless steel. 1 1/8” x 2 1/4” (29 mm x 57mm) square corner, beveled.
- Lock Chassis: Zinc plated for corrosion resistance.
- Latch Bolt: Steel, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
- Exposed Trim: Levers: Pressure cast zinc, plated to match finish symbols.
- Roses: Brass, bronze or zinc.
- Strike: ANSI curved lip strike 1 1/4” x 4 7/8” x 1 3/16” lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 21.
- Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
- Keying Options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
- Warranty: Ten-year limited for all functions including Vandlgard.
Function
Classroom
Finish
Satin Chrome
Backset
2-3/4 Inch
Strike
ANSI Strike
Design
Sparta
Series
ND Series
Color Code
626/US26D
Fire Rated
3 Hours {A}
Origin
Mexico
BAA Qualified
Yes
Package Height
4.75
Package Length
9.5
Package Volume
372.28125
Package Width
8.25
Warranty
10 year mechanical
Pack Size
1
Certifications and Listings
ANSI Certified
Door Handing
Universal/Reversible
Door Locks & Knobs Product Type
Classroom Levers
General Material
Brass
Hardware Finish Family
Chrome
Product Depth (in.)
9.5
Product Height (in.)
4.75
Product Width (in.)
8.25
Security/ANSI Grade
ANSI Grade 1 (Best)
Lock Type
Unkeyed
Handing
Reversible
UNSPSC
46171500
Aluminium Bottle Contents
Swinging
ProductType
Manual
Product Type
Cylindrical Lock
Handle Type
Lever
Door Thickness
1-5/8" to 2-1/8"
Rose Diameter
3-7/16 Inch
Finish Description
Satin Chrome
ANSI Function
F84
Latch Number
13-247
Latch Type
Deadlatch
Strike Number
10-025
Strike Type
ANSI Strike
ADA Compliant
YES
Finish Family
Satin Chrome
Strike Size
1-1/4" x 4-7/8"
Standards
ANSI/BHMA A156.2 Series 4000; ICC A117.1; CA Fire Code; Florida Building Code (ASTM E330, E1886, E1996) and Miami Dade (TAS 201, 202, 203) Requirements for Hurricanes; Meets FF-H-106C Series 161
Cylinder Type Used
Less Small Format Interchangeable Core
Function Description
Deadlocking latch bolt by levers. Outside knob/lever is locked by key in outside lever. Inside knob/lever is always free.
Front Size
1-1/8" x 2-1/4"
Function Family
Classroom
Strike Lip
1-3/16 Inch
Product Projection
2-15/16 Inch
Trim Material
Pressure Cast Zinc (Lever)
Features
Heavy-Duty Cylindrical Lock; Able to Handle any Application; Ideal for Both New Construction and Retrofit Applications
Grade
ANSI/BHMA Grade 1
Application
Healthcare; Education; Government; Office; Retail; Other Commercial Applications
Hand
Non-Handed
Manufacturer Parent
Allegion
Knob/Lever Size
4-9/16 Inch
Latch Throw
1/2 Inch
Sub-Series
ND70BD-SPA-626
Latch Bolt Material
Stainless Steel
Latch Corner
Square
Alternate Part Number-1
181501
IMAP Policy
Yes
Substrate Type
Zinc and Steel
Segment
Door Hardware
Duty Level
Heavy Duty
Collection
ND-Series
Keyed
Yes
Lever Style
SPA - Sparta
Keying
None (Select for Less Cylinder Options)
Cylinder and Keyways
S123
ANSI/BHMA Standards
F84
Standard Strike
10-025: ANSI, no box, 1-1/4" x 4-7/8" (1-3/16" Lip length) - Default Strike
Cylinder
BD - FSIC Prep Less Core
Electronic
No
Keys Included
2
Standard Latch
13-247: Deadlatch - 2-3/4" Backset - Square corner, 1-1/8" x 2-1/4"
Product Overview
The Schlage ND Series is a Grade 1 Cylindrical Lock that is easy to service and maintain. The ND Series Vandlgard is ideal for areas subject to abuse or anywhere vandalism is likely to be present. All ND Levers are reversible and ADA Compliant.
- Schlage ND series
- Classroom function
- Satin chrome finish
- Cylindrical lock
- Grade 1
- Straight lever
