ND Series Institution Large Format Less Core Rhodes with 13-247 Latch 10-025 Strike Oil Rubbed Bronze Finish

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Schlage ND82JD RHO 613 ND Series Institution Large Format Less Core Rhodes with 13-247 Latch 10-025 Strike Oil Rubbed Bronze Finish

Item #: ND82JD RHO 613 by Schlage Commercial

Brand: Schlage

See reviewsSee reviews
See reviews summary
In Stock

$827.24

/each
SAVE UP TO 82.72
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 13 units available

Finish: Dark Oxidized Satin Bronze Oil Rubbed

Cylinder: JD - Schlage FSIC Prep Less Core

PD - Conventional 6-pin Cylinder (Schlage C Keyway)
BD: Less SFIC Cylinder
JD - Schlage FSIC Prep Less Core
LD - Less Cylinder

Lever Type: RHO - Rhodes

ATH - Athens
BRK - Boardwalk
BRW - Broadway
LAT - Latitude
LON - Longitude
OME - Omega
RHO - Rhodes
SPA - Sparta
TLR - Tubular
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Institution, Both Levers Fixed, Entrance By Key in Either Lever
  • Handing: All ND-Series lever locksets are non-handed.
  • ANSI/BHMA Certified A156.2-2011
  • Door Thickness: 1 5/8” to 2 1/8” (41mm–54mm) standard including Vandlgard® functions. 1 3/4” - 2” for function ND85. See accessories for spacers required for 1 3/8” doors.
  • Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5” (60 mm, 95 mm, 127 mm) optional.
  • 1-5/8" to 2-1/8" Door Range
  • Faceplate: Brass, bronze or stainless steel. 1 1/8” x 2 1/4” (29 mm x 57mm) square corner, beveled.
  • Commercial Grade 1
  • UL Listed for 3 Hour Fire Door
  • Lock Chassis: Zinc plated for corrosion resistance.
  • Latch Bolt: Steel, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
  • Exposed Trim: Levers: Pressure cast zinc, plated to match finish symbols.
  • Roses: Brass, bronze or zinc.
  • Strike: ANSI curved lip strike 1 1/4” x 4 7/8” x 1 3/16” lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 21.
  • Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
  • Keying Options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
  • Warranty: Ten-year limited for all functions including Vandlgard.

Finish

613 - Oil Rubbed Bronze

Backset

2-3/4" Backset

Strike

ASA Strike

Design

Rhodes

Series

ND Series

Function

Institution

Color

Dark Oxidized Satin Bronze Oil Rubbed

Color Code

613/US10B

Fire Rated

3 Hours {A}

Origin

Mexico

BAA Qualified

Yes

Package Height

4.75

Package Length

9.5

Package Volume

372.28125

Package Width

8.25

Handing

Right Hand

Grade

Grade 1

ANSI/BHMA Standards

F87

Keyed

Yes

Handle Type

Lever

Collection

ND-Series

Keying

None (Select for Less Cylinder Options)

Cylinder

JD - Schlage FSIC Prep Less Core

Electronic

No

Door Handing

Non-Handed

Lever Type

RHO - Rhodes

Standard Strike

10-025: ANSI, no box, 1-1/4" x 4-7/8" (1-3/16" Lip length)

Substrate Type

Zinc and Steel

Keys Included

2

Lock Type

Cylindrical

Duty Level

Heavy Duty

Cylinder and Keyways

S123

IMAP Policy

Yes

Standard Latch

13-247: Deadlatch - 2-3/4" Backset - Square corner, 1-1/8" x 2-1/4"

Product Overview

Institution Lock Function, Grade 1, Cylindrical Lock, Schlage FSIC Less Core, Rhodes Lever, Dark Oxidized Satin Bronze Oil Rubbed

The Schlage ND Series is a Grade 1 Cylindrical Lock that is easy to service and maintain. The ND Series Vandlgard is ideal for areas subject to abuse or anywhere vandalism is likely to be present. All ND Levers are reversible and ADA Compliant.

A proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application.

The Schlage® ND family significantly exceeds BHMA Grade 1 requirements for cycle, hammer blow, lever torque, lever pull and other tests. This means confidence that the lock will last, whether the application calls for high abuse resistance or just operation over millions of cycles—without any degradation in performance.
