Schlage Commercial ND10S ATH 613 ND10S Athens Passage Lock, Oil Rubbed Dark Bronze
Item #: ND10S ATH 613 by Schlage Commercial
UPC #: 043156613878
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Passage, Both Levers Always Unlocked, Inside Lever is Always Free for Immediate Egress
- Handing: All ND-Series lever locksets are non-handed.
- ANSI/BHMA Certified A156.2-2011
- Door Thickness: 1 5/8” to 2 1/8” (41mm–54mm) standard including Vandlgard® functions. 1 3/4” - 2” for function ND85. See accessories for spacers required for 1 3/8” doors.
- Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5” (60 mm, 95 mm, 127 mm) optional.
- 1-5/8" to 2-1/8" Door Range
- Faceplate: Brass, bronze or stainless steel. 1 1/8” x 2 1/4” (29 mm x 57mm) square corner, beveled.
- Commercial Grade 1
- UL Listed for 3 Hour Fire Door
- Lock Chassis: Zinc plated for corrosion resistance.
- Latch Bolt: Steel, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
- Exposed Trim: Levers: Pressure cast zinc, plated to match finish symbols.
- Roses: Brass, bronze or zinc.
- Strike: ANSI curved lip strike 1 1/4” x 4 7/8” x 1 3/16” lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 21.
- Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
- Keying Options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
- Warranty: Ten-year limited for all functions including Vandlgard.
Function
10-Passage
Finish
Oil Rubbed Dark Bronze
Backset
2-3/4 Inch
Strike
ANSI, 1-1/4 Inch x 4-7/8 Inch, 1-1/4 Inch Lip, Square Corner
Design
Athens
Series
ND Series
Thickness
1-5/8" - 2-1/8"
Strike Number
10-025
Package Volume
372.28125
Latch Number
13-248
Color
Dark Oxidized Satin Bronze Oil Rubbed
Case Width
14.625"
Latch Type
Spring Latch
ANSI Function
F75
Hand
Not Handed
Grade
ANSI/BHMA Grade 1
Fire Rated
3 Hours {A}
Special Marks
Fire rated 3 Hours {A}
Strike Width
1-1/4"
Latch Backset Dim
2-3/4 In.
Lock Face Size
2-1/4 In. x 1-1/8 In.
Case Length
16.375"
Package Qty
1
Package Height
4.75"
Screws
Combination
Case Height
10"
Package Width
8.25"
Bolt Protection
1/2"
Case Volume
2394.84375
Color Code
613/US10B
Strike Type
ANSI Strike
Origin
Mexico
BAA Qualified
Yes
Rose/Escutcheon Design
3-7/16 In. Diameter
Base Material
Bronze
Strike Height
4-7/8"
Lever/Knob Design
ATH - Athens
Package Length
9.5"
Finish Description
Oil Rubbed Dark Bronze
Lever Style
ATH-Athens
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Projection
3.3125
Lever Length
4.5625
Door Thickness
1 5/8" - 2 1/8"
Bore Size
2.1250
ADA Approved
False
Application
Healthcare; Education; Government; Office; Retail; Other Commercial Applications
Warranty
10 year mechanical
Handle Type
Lever
Rose Diameter
3-7/16 Inch
Latch Throw
1/2 Inch
ADA Compliant
YES
Finish Family
Dark Bronze
Door Cross Bore
2.125 Inch
Standards
ANSI/BHMA A156.2 Series 4000; ICC A117.1; CA Fire Code; Florida Building Code (ASTM E330, E1886, E1996) and Miami Dade (TAS 201, 202, 203) Requirements for Hurricanes; Meets FF-H-106C Series 161
Function Description
Latch retracted by knobs/levers at all times
Front Size
1-1/8" x 2-1/4"
Function Family
Passage/Hall/Closet
Strike Lip
1-3/16 Inch
Product Projection
3-5/16 Inch
Trim Material
Pressure Cast Zinc (Lever)
Features
Heavy-Duty Cylindrical Lock; Able to Handle any Application; Ideal for Both New Construction and Retrofit Applications
Strike Size
1-1/4" x 4-7/8"
Manufacturer Parent
Allegion
Lever Length-Inches
4.5625 Inch
Latch Corner
Square
Knob/Lever Size
4-9/16 Inch
Latch Bolt Material
Stainless Steel
Lever Style Family
Straight Lever
Sub-Series
CL_Cylindrical_Locks_schlage_commercial_215
Alternate Part Number-1
172764
Product Overview
ND SeriesCylindrical Locks
ND Series locks have been the most popular Schlage product ever since Walter Schlage invented the cylindrical lock in 1920. The ND Series is ANSI/BHMA Grade 1 certified and performs beyond the Grade 1 standards. The lock withstands 3,100 in-lb. of abusive lever torque, as well as 1,600 lbs. of offset lever pull for protection against pry bar attacks. The lock is not only strong from attacks, but it also shows nearly zero droop or wobble after 16 million cycles.
All ND Series locks come in 10 finishes, nine lever designs and use an ANSI 161 door preparation, commonly used with cylindrical locks. They are ideal for all new construction and retrofit applications.
Product Specifications: Material:- Modular design of zinc and steel components plated for corrosion protection
- Standard: 1 5/8" to 2 1/8"
- Non-Handed
- Standard: Nine designs, pressure cast zinc, plated to match product finish specification
- Wrought brass, bronze, or zinc, plated to match product finish specification
- 10 available
- (605, 606, 612, 613, 619, 622, 625, 626, 626AM, 643e)
- Standard: 2 3/4"
- Standard : 1 1/8" x 2 1/4"
- Standard : 1/2" throw via Oil Impregnated Stainless Steel
- Standard: ANSI Curved Lip: 1 1/4" x 4 7/8" x 1 3/16"
- Standard: 3 Schlage
- (KIL or FSIC or SFIC)
- Standard: 6-Pin Patented Everest 29
- 10 years mechanical, 1 year wired electrified
- All ND Series comply with A156.2 performance requirements for grade 1 cylindrical locks. Wired electrified complies with A156.25 (indoor), wireless electronic complies with A156.25 (indoor/outdoor) requirements for electrified locking devices
- Complies with ICC A117.1 Accessible and Usable Buildings and Facilities
- All locks 3 hour A label single firedoor 4'0" x 10'0"
- pair doors 3 hour firedoor 8'0" x 8'0" with 3/4" latch option
- pair doors 90 minute fire 8'0" x 10'0" with 3/4" latch option
- All levers with a return to door of 1/2"
- (64 mm) or less comply
(Rhodes, Sparta, Tubular, Omega, Longitude and Boardwalk)
- Complies with Florida Building Code (ASTM E330, E1886, E1996) and Miami Dade (TAS 201, 202, 203) requirements for hurricanes
- Meets FF-H-106C Series 161
