Schlage ND80PDEU ATH 605 ND Series Storeroom C123 Keyway Electrically Unlocked Athens with 13-247 Latch 10-025 Strike Bright Brass Finish
Item #: ND80PDEU ATH 605 by Schlage Commercial
Brand: Schlage
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Storeroom Electrical, Outside Lever Continuously Locked Electrically, Unlocked By Key Outside or By Switch or Power Failure, Auxiliary Latch Deadlocks Latchbolt When Door is Closed, Inside Lever Always Unlocked for Immediate Egress
- Door thickness: 1 5⁄8" to 21 ⁄8" (41 mm–54 mm) standard including Vandlgard® functions. 1 3⁄4" - 2” for function D85. See accessories (Page 21) for spacers required for 1 3⁄8" doors.
- Backset: 2 3⁄4" (70 mm) standard. 2 3⁄8", 33⁄4" and 5" (60 mm, 95 mm, 127 mm) optional.
- ANSI/BHMA Certified A156.2-2011
- 1-5/8" to 2-1/8" Door Range
- Faceplate: Brass, bronze or stainless steel. 11 ⁄8" x 21 ⁄4" (29 mm x 57 mm) square corner, beveled.
- Lock chassis: Zinc plated for corrosion resistance.
- Commercial Grade 1
- UL Listed for 3 Hour Fire Door
- Latch bolt: Steel, 1 ⁄2" (12 mm) throw, deadlocking on keyed and exterior functions. 3⁄4" (19 mm) throw anti-friction latch available for pairs of fire doors.
- Exposed trim: Levers: Pressure cast zinc, plated to match finish symbols. Roses: Brass, bronze or zinc.
- Strike: ANSI curved lip strike 11 ⁄4" x 47 ⁄8" x 1 3⁄16" lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 21.
- Cylinder and keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
- Keying options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
- Warranty: Ten-year limited for all mechanical functions including Vandlgard; 1 year limited for electrified functions.
Finish
Bright Brass
Backset
2-3/4" Backset
Strike
ASA Strike
Design
Athens
Series
ND Series
Function
Storeroom Electrically Unlocked (Fail Secure)
Color Code
605/US3
Origin
Mexico
BAA Qualified
Yes
Package Height
4.75
Package Length
9.5
Package Volume
372.28125
Package Width
8.25
Fail Safe / Fail Secure
Fail-Secure
Substrate Type
Zinc and Steel
Lever Type
ATH - Athens
Door Handing
Non-Handed
Segment
Door Hardware
Latch Type
14-047 (Standard)
Duty Level
Heavy Duty
Grade
Grade 1
Keyed
Yes
Cylinder Type
P - Conventional Cylinder 6-pin (C Keyway)
Handle Type
Lever
Lock Type
Cylindrical
Keying
None (Select for Less Cylinder Options)
Cylinder and Keyways
S123
Standard Strike
10-025: ANSI, no box, 1-1/4" x 4-7/8" (1-3/16" Lip length)
Electronic
Yes
Keys Included
2
Standard Latch
13-247: Deadlatch - 2-3/4" Backset - Square corner, 1-1/8" x 2-1/4"
Product Overview
Electrified Cylindrical Lock, Storeroom, 12-24VAC/DC, Fail Secure, Athens Lever, Bright Brass
ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
Electrified Schlage ND80 cylindrical lock - 12 or 24 VDC.
Not only do you get our toughest Grade 1 cylindrical lock, that is ideal for use in schools, hospitals, offices, retail spaces, colleges, universities and other applications. You also get the promise of continuous improvements and innovations and our greatest warranty backing your project.
