Pentair 160301 Pool Filter Cartridge Clean & Clear Plus 420 Sqare Feet Almond
Item #: 160301 by PENTAIR WATER POOL AND SPA INC
UPC #: 788379670139
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Superior strength
- Enhanced Dirt Capacity: The expansive filter area increases dirt-holding capacity, extending intervals between cleanings.
- High Flow™ manual air relief valve
- User-Friendly Maintenance: Cartridges are easily removable and can be rinsed clean with a standard garden hose, simplifying the cleaning process.
- Integrated continuous High Flow™ internal air relief is operational only when there is unobstructed flow in the circulating system
- Optimized Water Flow: Equipped with 2-inch plumbing to maximize flow rates, facilitating faster water purification.
- Sturdy Construction: The injection-molded tank offers superior strength and long-term reliability.
- Pentair Aquatic Systems does not recommend flow rates above 150 gpm
- Efficient Drainage: Features a 1.5-inch, 100% drain clean-out port for swift maintenance and winterization.
- Actual system flow will depend on plumbing size and other system components
- Large filter area for increased dirt capacity
- Continuous High Flow Internal Air Relief: Ensures optimal filtration efficiency by preventing air accumulation within the system.
- 1-1/2 Inch, 100% drain clean-out port
- Continuous High Flow™ internal air relief
- Injection molded tank
- Balanced hydraulic flow
- Tension Control™ clamp
- 100% factory tested
- Black bulkhead unions
Application
For pool and spa (bather) applications
Shipping Dimensions
23.25x22.25x45.75
Brand
Pentair
Department
FILTERS
FiltrationArea
420 sq-ft
FlowRate
150 gpm (Residential)
Item
Cartridge Filter
MaximumContinualOperatingPressure
50 psi
MaximumOperatingWaterTemperatureInternalFilter
104 deg F
ModelNumber
CCP420
StandardsApprovals
NSF Listed, ANSI Standard 50 Certified
SubBrand
Clean & Clear® Plus
TankMaterial
Fiberglass Reinforced Polypropylene
TurnoverCapacity
8 hr - 72000 gal, 10 hr - 90000 gal, 12 hr - 108000 gal
Product Weight
75 pound
Maximum Working Pressure
50 pounds per square inch
Product Height
49 inch
Maximum Flow Rate
150 gal/min
Pipe Size
2 inch
P65 Warning
The following product(s) can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
Tank Diameter
22.98 inch
Tank Material
Fiberglass
Distance Between Inlet/Outlet
7.49 inch
Cartridges Required
4
Each Product Weight
75 pound
Side Clearance
6 inch
Distance Inlet and Base
17.54 inch
Vertical Clearance
68 inch
Green or Energy Efficient Product
True
Minimum Sell Quantity
1
Turnover 8hrs
72000 gallon
Tank Color
Beige
Filtration Area
420 square feet
Filter Tank Molding Type
fiberglass-reinforced
Distance Outlet and Base
8.05 inch
Plumbing Size
2 inch
Design Flow Rate
150 gal/min
Standards Approvals
ANSI Standard 50 Certified
Turnover 6hrs
54000 gallon
Turnover 12hrs
108000 gallon
Commercial or Residential
Residential
Pool Type
In-Ground
Effective Filtration Area
420 sq ft
Finish
Almond
Material
Plastic
Package Quantity
1
UL Listed
No
ADA Compliant
No
UNSPSC
49241700
MADE IN THE USA
Yes
Assembled Product Height
49 in.
Assembled Product Width
24 in.
GSA Approved
No
AbilityOne
No
TAA/BAA Compliant
Yes
Product Overview
The Pentair Clean & Clear Plus Cartridge Pool Filter (Model 160301) is engineered to deliver top-tier filtration with minimal upkeep. Its robust, corrosion-resistant, injection-molded, fiberglass-reinforced polypropylene tank ensures exceptional durability and reliability. The filter employs four nonwoven polyester cartridges, providing a substantial filtration area of 420 square feet, which efficiently captures dirt and debris without necessitating backwashing.
This filter is part of Pentair's Eco Select Brand, highlighting its energy-efficient design. The efficient water flow allows for the use of smaller pumps or lower pump speeds, thereby reducing energy consumption. Additionally, rinsing cartridges instead of backwashing conserves water.
