CRL Z912PS Polished Stainless Z-Series Square Type Flat Base Stainless Steel Clamp for 1/2" Glass
Item #: Z912PS by CR Laurence
See reviews See
reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How
Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- For 1/2" (12 mm) Glass Thickness
- Replacement Gaskets are Available by Ordering Cat. No. Z12SG
- For Use on Mezzanines, Partitions, Railings and Windbreaks
- Use Monolithic Tempered Glass
- Steel Pin Available for Additional Glass Support
- Custom Painted Finishes Available Upon Request
- Tested and Engineered to Meet and Exceed Code Standards (Engineering Reports)
Height
2-5/16
Shipping Weight
8 oz (227g)
Width
2-1/8
Finish
Polished Stainless
Type
Flat Base & Fits 1/2" Glass
Material
Stainless Steel
Depth
1-7/32
Glazing Thickness
1/2
Profile
Square
Finish/Color
Polished Stainless Steel
CRL Polished Stainless Z-Series Square Type Flat Base Stainless Steel Clamp for 1/2" Glass is used to position glass thickness of 1/2" (12 mm) in railings. The flat base allows for installation onto square tubing or other flat surfaces. The clamp includes an optional steel pin for additional weight support. These clamps are the perfect solution for partitions, railings, windbreaks and countless other projects. CRL Brushed Stainless Z-Series Square Type Flat Base Stainless Steel Clamp for 1/2" (12 mm) Glass has been tested and engineered to meet and exceed code standards and legal requirements. Specifications: Glass Thicknesses: Models for 1/4" to 1/2" (6 to 12 mm). Base Design: Flat. For Use With: Square Tubing or Other Flat Surfaces. Material: Choice of Zinc Constructed or Stainless Steel. Stainless Steel or Powder Painted Zinc Clamps are recommended for more durability in exterior applications. Glass Fabrication: For 1/4" (6 mm), 5/16" (8 mm), and 3/8" (10 mm) Thick Glass: 1/2" (12 mm) diameter hole required if using provided steel pin for glass support. For 1/2" (12 mm) Thick Glass: 9/16" (14 mm) diameter hole required if using provided steel pin for glass support. Includes: Rubber Gaskets and Steel Pin (for optional use) with Grommet. Important Notes For interior and exterior applications CRL recommends pinning each glass panel as required when the glass is not supported from the bottom edge to prevent glass panel slippage. Rubber gaskets and steel pins are provided with each clamp. DS 06/28/2016
From Manufacturer
This CRL Z-Series Square Type Flat Base Glass Clamp is designed to be used on glass 1/2" (12 mm) thickness. Constructed from either zinc or stainless steel, the clamps are the perfect solution for partitions, railings, windbreaks and countless other projects.
For securing the Z-Clamp to thin wall tubing (less than 1/8”), use CRL’s ZB0LT Socket Head Cap Bolt andZRNUT Rivet-Nut. For installation, drill a 17/32” (13.5 mm) hole, then install the Rivet-Nut using 34604 Heavy-Duty Thread Insert tool and 34618 5/16” Mandrel and Nosepiece.
NOTE: 9/16" (14.3 mm) hole is required if using the steel pin (included with the clamp) for additional glass support.
SPECIFICATIONS:
Glass Thicknesses: For 1/2" (12 mm).
Base Design: Flat
For Use With: Square Tubing or Other Flat Surfaces
Material: Choice of Zinc Constructed or Stainless Steel. Stainless Steel or Powder Painted Zinc Clamps are recommended for more durability in exterior applications.
Glass Fabrication:
Includes: Rubber Gaskets and Steel Pin (for optional use) with Grommet
Replacement Hardware: CRL P612 for Replacement Screws
Product Warning:
For interior and exterior applications CRL recommends pinning each glass panel as required when the glass is not supported from the bottom edge to prevent glass panel slippage. Rubber gaskets and steel pins are provided with each clamp.
.
Stainless Steel Advisory: Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
