30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Base Material
Stainless Steel
Special Marks
Fire rated 3 Hours {A}
Package Qty
1
Knuckles
5
Bearing Type
Ball Bearing
Fire Rated
3 Hours {A}
Hinge Type
Hinge, Full Mortise
Mounting Style
5/8" Radius
Color Code
630/US32D
Color
Satin Stainless Steel
Weight
Residential Weight
Width
4 In.
Pin Type
Removable
Height
4 In.
Packaging
2 pack with fasteners
Material
Stainless Steel with Stainless Steel Pin
Pin Diameter
.234"
Fastenersize-Wood
3/4" x 9" FH
Size
- 3-1/2" X 3-1/2"
- 4" X 4"
Gauge
.085"
Notes
- Hager residential hinges are provided without lubrication. We recommend lubricating the hinges after installation.
- All residential hinges conform to the "Light Weight" requirements of ANSI A156.1.
HINGE WIDTH in. - RESIDENTIAL
4
Fastener Size - Wood
3/4" x 9" FH
HINGE HEIGHT in. - RESIDENTIAL
4
HINGE TIPS
NON REMOVABLE PIN
HINGE FINISHES - RESIDENTIAL
US32D - SATIN STAINLESS STEEL
Notes:
- Hager residential hinges are provided without lubrication. We recommend lubricating the hinges after installation.
- All residential hinges conform to the "Light Weight" requirements of ANSI A156.1.
Certifications:
ANSI A5114
Features:
Reversible. Round corners - 5/8" (16 mm) radius. Removable pin.
Finishes:
US32D
