Richelieu Hardware WEBKIT1257083Click To Copy HAWA JUNIOR 120 A System

soft close
Designed for sliding wood doors weighing up to 120 kg (264 lb) each, the HAWA JUNIOR 120 A System is a suspended sliding system equipped with a two-way suspension plate at the top of the door. Opt for the standard hardware set with stoppers or upgrade to the robust soft-close mechanism.
Features:
- For door thickness of 35 to 80 mm (1-3/8" to 3-1/8")
Track options:
- Standard ceiling track for surface and recessed mount
- Removable track profile for pocket door applications
Track stopper with damper and adjustable retention spring resists door bounce-back.
Robust soft close mechanism for commercial applications.
Minimum door width: 1150 mm (45 1/4 in) for soft close in both directions; can be used for pocket doors.
This is an ideal solution for residential, commercial, and institutional projects. It is suitable for kitchens, offices, examination and consultation rooms in medical clinics, meeting rooms, bedrooms, and washrooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
A groove must be machined into the bottom of the door for a rattle-free floor guide.
For door width greater than 1500 mm (59 in), add a floor guide for greater stability.
Advantages And Benefits
- Track stopper with adjustable retention spring to resist door bounce-back
- Minimum door width 1150 mm (45-1/4 in) for soft close in both directions
Important Information
- Pictures provided for visual reference only: actual product may vary.
- All required hardware should be ordered and obtained prior to initiating fabrication or installation work. Please verify that the parts and quantities listed in your order are correct before proceeding to checkout.
- Always use instructions provided by the manufacturer, as included with the product. The manufacturer reserves the right to amend, modify, or otherwise supplement any previously issued product and/or technical information, as deemed required from time to time, without prior notice.
- The documentation, drawings, and instructions on this page apply to the system described on this page only. Richelieu expressly declines all responsibility for any design or construction that combines this system with systems from this same manufacturer or systems from other manufacturers.
- Installation of the product shall be executed by qualified individuals only, always ensuring that each product is securely installed using proper fixation methods, as appropriate for each applicable substrate. We trust that anyone installing these products has the required skills, knowledge, and experience. Richelieu expressly disclaims any liabilities for results obtained through improper use or installation.
- Always remove debris/dust/residue (sawdust and/or aluminum) from all tracks and guide channels using a dry cloth during installation and before operating the system.
- Never spray lubricant on this product.
