Alarm Lock DL3575CRR US3 Right Hand Classroom Digital Mortise Lock Bright Brass Finish
Item #: DL3575CRR US3 by Alarm Lock
Brand: Alarm Lock
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Supports 300 3-6 Digit PIN Codes
- 300 User codes: Master, manager, supervisor & basic users
- Audit Trail and Timed Locking
- Fingertip or Windows PC-programmable
- Real time clock enables up to 500 scheduled events and holiday schedules
- Multi-Level User Codes and One-Time Service Codes
- 40,000 Event audit trail provides a printed time/date- stamped log of all electronic activity
- Long-life battery pak for 80,000 cycles, typical and low-battery alert
- Long Battery Life and Low Battery Alert
- Choose either classroom or deadbolt versions and left or right handing (If reverse hand is required, lock is field reversible.)
- 1 3/8” (3.5 cm) mortise cylinder supplied card enrollment mode allows many cards to be quickly added without PC –also– downloadable from PC or prox enroller tool
- 40,000 event audit trail log
- 500 scheduled events, e.g., lock or unlock
- PC programming/reporting
- Quick passage mode (without being in program mode)
- Program data transferred to lock via AL-PCI2 or AL-DTMIII
- 5AA battery-pak operated; 75,000 cycles, typical
- 3 Architectural finishes (US3 polished brass, 26D satin chrome, 10B duronodic)
- Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)
Finish
Bright Brass
Function
Entry
Series
DL Series
Design
Digital Keypad
Handing
Right Hand
Strike
1-1/4" x 4-7/8" Strike
Backset
2-3/4"
Grade
Grade 1
Power
Battery Pack
Color Code
605/US3
Door Thickness
1-3/8 In. to 1-7/8 In.
Cylinder Type
Mortise Cylinder
Fire Rated
3 Hours {A}
Package Height
4.875"
Package Length
13"
Package Volume
728.8125
Package Width
11.5"
Number of users
300
Keypad Type
Electronic
Lock Platform
Mortise Latch
Package Qty
1
Programmer
Optional
Reader Technology
Keypad Only
Software
Optional
Special Marks
Fire rated 3 Hours {A}
Strike Type
Mortise
Base Material
Brass
Product Overview
Pushbutton Classroom Mortise Lock, 300 Users, 40,000 Event Audit Trail, Weatherproof, Regal Lever, Right Hand or Left Hand Reverse, Bright Brass
Trilogy high security mortise locks with and without prox DL3500 Series Mortise Locks 300 User codes: Master, manager, supervisor & basic users Fingertip or Windows PC-programmable Real time clock enables up to 500 scheduled events and holiday schedules 40,000 Event audit trail provides a printed time/date- stamped log of all electronic activity Long-life battery pack for 80,000 cycles, typ. and low-battery alert Choose either classroom or deadbolt versions and left or right handing (If reverse hand is required, lock is field reversible.) 1 3/8 In. (3.5 cm) mortise cylinder supplied card enrollment mode allows many cards to be quickly added without PC -also- downloadable from PC or prox enroller tool 40,000 event audit trail log 500 scheduled events, e.g., lock or unlock PC programming/reporting Quick passage mode (without being in program mode) Program data transferred to lock via AL-PCI2 or AL-DTMIII 5AA battery-pak operated; 75,000 cycles, typ. 5 Architectural finishes Weatherproof -31 Deg. to +151 Deg. F (-35 Deg. to +66 Deg. C)
Trilogy Mortise: High security digital locks.
Trilogy high security mortise locks with and without prox DL3500 Series Mortise Locks 300 User codes.
