Features
Package Qty
1
Function
Cement Case
Product Type
Door Control Part/Accessory
Series
40 Series
Manufacturer Parent
Assa Abloy
For Use With
Model H40; Model 30; 40 Closers
Sub-Series
403000
ADA Compliant
No
Function Family
Part/Component
Included Components
Cement Case; Screws
Hazardous Material
No
Design
NULL
Grade
Grade 1
Package
No
Door Swing
Single Acting
Door Weight
350 lbs.
Cover Type
Cycolac, rust-proof cement case
Variant
Cement Case
Duty Level
Heavy Duty
Hold Open Feature
No
Hang Type
Offset Hung
Parts and Accessories Type
Installation Accessories
Traffic Rating
High Traffic
Product Overview
Norton Rixson 403000 Heavy Duty Center Hung Floor Closer Cement Case Package
The 40 is a double-acting, center-hung floor closer designed with a centering arm with adjustment screws for interior or exterior doors weighing up to 300lbs
Product overview Features- Double acting, non-handed
- Interior or exterior doors
- 340 top pivot included
- Available non-hold open (N) or automatic hold open (A) at 90 degree (requires 93 degree swing) or 100 (requires 103 degree swing)
- Maximum door opening 103 degree
- Centering arm with adjusting screws in face of door (critical for double acting doors)
- Adjustable closing speed valves for each direction of door swing
- Mechanism returns door to center
- Auxiliary door stop required, overhead or floor type
- Not allowed for fire rated doors
- Available with floor plate or threshold installation
- Furnished with wood and machine screws
- Extended spindles available in 1/2" increments up to 2" longer than standard
- Sizes up to 4 ft 0" x 8 ft 6"
- Door weight up to 300lbs.
- Aesthetically appealing way to support and control the door
- Constructed with robust materials and internal components for long life and consistent operation
- Weight of door is supported by floor closer
- Closer Type:Floor
- Maximum Door Weight:300 lbs
- Traffic Rating:High Traffic
- Warranty:10-year limited warranty
- Buy American Act*
*Domestic Sourcing regulations vary greatly within Federal, state and local government agencies and therefore certain restrictions may apply. Please contact BAACompliance.Americas@assaabloy.com for additional information.
- Certain models meet ANSI A117.1 (PH prefix)
