RobbJack FM-305-24-BN Ball End Mill: 0.75" Dia, 0.75" LOC, 3 Flute, Solid Carbide Bright/Uncoated
Item #: FM-305-24-BN by RobbJack
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Flute Type
Helical
Shank Type
Straight-Cylindrical
Helix Angle
40
Number of Flutes
3
Chipbreaker
No
Length Type
Extended
Cutting Direction
Right Hand
Series
FM-305
System of Measurement
Fractional Inch
Variable Helix
No
Coating/Finish
Bright/Uncoated
Coolant Through
No
Length of Cut (Inch)
3/4in
Manufacturers Catalog Number
FM-305-24-BN
Neck Length (Inch)
3in
Overall Length (Decimal Inch)
6.0000in
Overall Length (Inch)
6in
Primary Workpiece Material
Non-Ferrous Metal
Primary Workpiece Material Code
N
Shank Diameter (Decimal Inch)
0.7500
Shank Diameter (Inch)
3/4in
UNSPSC Code
27112803
Vendor Drop Ship
Y
Coating Classification
Uncoated
End Mill Material
Solid Carbide
Extended Reach
Yes
Flute Direction
Right Hand
Helix Style
High
Material Removal Type
Roughing & Finishing
Mill Diameter (Decimal Inch)
0.7500in
Mill Diameter (Inch)
3/4in
Neck Length (Decimal Inch)
3.0000
Single Or Double End
Single
Variable Index
No
Reach Length (Inch)
3-3/4
Nose Radius (Decimal Inch)
0.3750
Reach Length (mm)
95.25
Mill Diameter Tolerance
0.0010/ 0.0015 in
Reach Length (Decimal Inch)
3.7500
Overall Length Tolerance
+0.0600/-0.0600 in
Neck Diameter (mm)
18.10
TIR Maximum (mm)
0.01
TIR Maximum (Decimal Inch)
0.0005
Shank Diameter Tolerance
0.0001/ 0.0002 in
Product Overview
Ball End Mill: 0.75" Dia, 0.75" LOC, 3 Flute, Solid Carbide 6" OAL, 3/4" Shank Dia, 40 degree Helix, Uncoated, Single End, Series FM-305
