Robertshaw 801 LINE VOLTAGE THERMOSTAT WITH SINGLE-POLE SINGLE-THROW, HEAT ONLY
Item #: 801 by Robertshaw
UPC #: 020967008017
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Program Type
None
Color
White
Heat Stages
1
HVAC Product Type
Thermostat
Product Width (in.)
2.9
Product Height (in.)
2.8
Pack Size
1
Product Depth (in.)
2.8
Thermostat Product Type
Non-Programmable Thermostat
UNSPSC
41112209
Included
No Additional Items Included
A line voltage thermostat with the performance and accuracy of a low voltage control. The Robertshaw 800 series are universal replacements for many other brands and can be used to retrofit most existing electric heat thermostats. With models for heating that include single-line break and double-line break.
- Vertical mount
- Convenient Temperature Display - View comfort level at-a-glance.
- Bimetal Temperature Sensing - For improved thermal performance.
- Mercury-Free - No leveling or special disposal required.
- J-Box Compatible - Not only will it meet code, but it speeds up installation.
- Positive-Off - Assured shutdown of HVAC system.
- Universal Replacement - Can retrofit most existing electric heat thermostats.
- Electrical rating: 18-25 Amp, 120/240/277 VAC Non-Inductive, 1/4 HP, 120 VAC, 1/3 HP, 240 VAC, 125 VA Pilot Duty Temperature
- Control range: 50° to 90°F (10° to 32°C)
- Accuracy: +/-2°F
- Color - White
