Grooving Insert: N123KGF 1125, Solid Carbide TiAlN

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Sandvik Coromant 5736922 Grooving Insert: N123KGF 1125, Solid Carbide TiAlN

Item #: 5736922 by Sandvik Coromant

See reviewsSee reviews
See reviews summary
In Stock

$81.17

/each
SAVE UP TO 8.12
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 344 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Insert Material

Solid Carbide

Series

CoroCut 1-2

Coating Process

PVD

Coating/Finish

TiAlN

Corner Radius (Decimal Inch)

0.0315

Manufacturers Catalog Number

N123K2-0635-0008-GF 1125

Overall Length (Decimal Inch)

0.9862

Overall Width (Decimal Inch - 4 Decimals)

0.2500

Overall Width (Inch)

1/4

UNSPSC Code

23242105

Vendor Drop Ship

N

Cutting Width (Decimal Inch)

0.2500

Cutting Width (Inch)

1/4

Insert Thickness (Decimal Inch)

0.1713

Maximum Depth of Cut (Decimal Inch)

0.9488

Multi-use Tool

Yes

Overall Width (mm)

6.35

Rake

Neutral

Insert Hand

Neutral

Rake Angle

7.00

Chip Breaker

GF

Insert Style

N123

Maximum Depth of Cut (mm)

24.10

Cutting Height (Decimal Inch)

0.1713

Minimum Corner Radius (Decimal Inch)

0.0295

Manufacturer Grade

1125

Maximum Depth Of Cut Range (Decimal Inch)

0.3000 to 1.0000

Insert Seat Size

K

Maximum Depth Of Cut Range (mm)

20.00+

Corner Radius (mm)

0.80

Cutting Width (mm)

6.35

Iso Code

N123K2-0635-0008-GF 1125

Maximum Corner Radius (Decimal Inch)

0.0335

Cutting Height (mm)

4.35

Product Overview
Grooving Insert: N123KGF 1125, Solid Carbide TiAlN Finish, Neutral, 6.35 mm Cutting Width, 24.1 mm Max Depth, Series CoroCut 1-2
