CRL GR0V4SA Satin Anodized 4" x 2-1/2" Oval Extruded Aluminum Cap Rail for 1/2" or 5/8" Glass
Item #: GR0V4SA by CR Laurence
See reviews See
reviews
In Stock $611.37 /each
SAVE UP TO 61.14
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business day
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How
Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- Available for 1/2", 9/16" or 5/8" (12, 13.52, or 16 mm) and 3/4" (19 mm) Glass
- Available for 1/2", 9/16" and 5/8" (12, 13.52, or 16 mm) Glass
- Connects to a Variety of Fabricated Corners and End Caps
- Custom Shapes and Sizes are Available
- Use Sleeve Number GR0V4CSM
"D" Depth
1-1/4" (31 mm)
"W" Width
3/4" (19 mm)
Length
240
Type
Extruded Cap Rail
Grade
6063-T6
Thickness
.125" (3.2 mm)
Finish
Satin Anodized
Height
2-1/2
Material
6063-T6 Aluminum
Depth
1-1/4
Width
4
Glazing Thickness
1/2 or 5/8
Profile
Oval
Finish/Color
Satin Anodized
CRL Extruded Aluminum Cap Rails are extruded from alloy 6063-T6, which is suitable for custom finishes such as anodizing, powder coating, etc. Use of our 32629 Metal Contact Cement is required to achieve a secure and permanent bond at all connections. Use Connector Sleeves to connect Cap Rails.
Please contact DK Hardware Sales for more information or a quote.
NOTE: Cat. No. GR5PV Cap Rail Vinyl and 95CBL Silicone should be used to secure 1/2" (12 mm) glass; Cat. No. LR56PV Cap Rail Rubber Insert and 95CBL should be used to secure 9/16" (13.52 mm) laminated glass; Cat. No. 95CBL Silicone and shims should be used to secure 5/8" (16 mm) glass.
This dimension is used to calculate the glass size. Add the clearance you desire or allow an additional 1/8" (3.2 mm) if using Cap Rail Vinyl.
.
