Satin Anodized S55 Monterey Bi-Fold 2 Panel Right Hand Exterior Swing with Flush Sill

Roll over image to zoom in

CRL Satin Anodized S55 Monterey Bi-Fold 2 Panel Right Hand Exterior Swing with Flush Sill

Item #: M5A02F0SA by CR Laurence

Brand: CRL

See reviews
See reviews summary

Finish: Satin Anodized

Configuration: 2 Panel Right Hand

2 Panel Left Hand
2 Panel Right Hand

Series: S55

S55
S80

Frame Depth: 2-5/16

2-5/16
3-3/16

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Easy to Operate Panels
  • Fully Assembled, Ready for Glazing
  • New Construction or Retrofit, Commercial and Residential
  • Thermally Broken Option Available
  • Weather Resistant, Designed for Interior/Exterior Use

Swing Type

Right Hand Exterior Swing

Type

2 Panel

Finish

Satin Anodized

Maximum Panel Weight (Pounds)

170 Lbs.

Maximum Height Interior Application (Inches)

120"

Glazing Type

Tempered Insulated,Tempered Monolithic,Tempered Laminated

Frame Depth

2-5/16

Swing

Outswing

Configuration

2 Panel Right Hand

Glazing Thickness

3/4, 1, 1/4, 3/8, 1/2

Minimum Overall Opening Width (Inches)

38"

Door Type

Framed Bi-Folding Doors

Top Hung

Yes

Panel Thickness

2-1/8

Panel Stile Width (Inches)

2-3/8"

Flush Sill

Yes

Finish/Color

Satin Anodized

Series

S55

2 Point Lever Latch

Yes

Maximum Height Interior Application

120 in. (3048 mm)

Maximum Panel Weight

170 lbs. (77.1 kg)

Minimum Overall Opening Width

38 in. (965 mm)

Panel Stile Width

2-3/8 in. (60 mm)

Product Overview

The Monterey Bi-Folding Glass Wall System allows you to bring in the outdoors while providing resistance to undesirable weather conditions. Available in Standard or Thermally Broken series with countless configurations available to create large living spaces that seamlessly transition outdoors to indoors. Our precision engineered components provide a system that slides smoothly with minimal effort while supporting multiple panels in a single opening. The Monterey Series provides security with two point interior lever latch as standard with three point keyed locks available on some configurations. It is the most contemporary way to maximize the space available in residential or commercial properties, while at the same time creating stunning areas with brilliant transparency.
Monterey Bi-Folding Glass Wall Systems can accommodate door configurations ranging from 2 to 26 panels and allows them to be stacked with minimum effort to one or both sides, leaving an enormous wide open space. A pivoting door, that will also fold up with the entire system, can be incorporated into many configurations. Design options are virtually limitless. The sturdy, yet slim frame construction allows for more glass and less metal. The Monterey Series is designed for 1/4" to 1-1/4" (6 to 32 mm) glazing thickness, and the frames are available in white, black, and wood grain powder coated, satin and black bronze anodized finishes as standard with custom finishes also available.

.
