Schlage Commercial PC10BRW625 Performance Series Passage Latch Cylindrical Lock with Broadway Lever with 47272065 Latch and 47267101 Strike Bright Chrome Finish
Item #: PC10BRW625 by Schlage Commercial
Brand: Schlage Commercial
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Tested and certified to ANSI/BHMA Grade 1 operational and security standards; FSIC Interchangeable core cylinders meet Grade 2 security standards and SFIC Interchangeable core cylinders meet Grade 3 security standards. Optional 2-3/8" backset latches meet BHMA Grade 2
- Available in 8 functions; four keyed, two non-keyed, two dummy functions
- Design-forward styles including 8 levers, 1 rose, and 6 finishes that perfectly suite with ND & ALX Series
- Modular design of zinc and steel components plated for corrosion protection
- Outside cast steel spindle construction exceeds 2 million cycles (2x the BHMA standard)
Diameter
3-11/25" Rose
Projection
3-1/10"
Finish
Bright Chrome
Dimension
4-1/2" Lever Length with 3-1/10" Projection with 3-11/25" Rose
Material
Zinc
Backset
2-3/4" Backset
Handing
Reversible
Function
Passage Latch
Strike
ASA Strike
Fire Rated
Yes
Manufacturer Warranty
Limited 5 Year Warranty
Rose/Escutcheon Design
Rhodes Rose
UL Listing Type
3 Hour Fire
Door Range
1-3/8" to 1-3/4"
Hazardous Material
No
Strike Dimension
1-1/4" x 4-7/8"
Cross Bore Size
2-1/8" Bore
Finish code
625
Series
PC Series
Latch Faceplate Dimension
1-1/8" x 2-1/4"
Lever Knob Design
Broadway Lever
No of inners
1
Grade
ANSI/BHMA Grade 1
Warranty
5-Year Limited Mechanical Warranty
Color Code
625/US26
Door Thickness
1-3/8" to 1-3/4"
Rose Diameter
3.44 Inches
Cylinder Type
Non-Keyed
Latch Throw
1/2 Inch
Finish Description
Bright Polished Chrome
ANSI Function
F75
Strike Type
ANSI Strike
ADA Compliant
YES
Finish Family
Polished Chrome
Lever Style
BRW-Broadway
Strike Size
1-1/4" x 4-7/8"
Rose/Escutcheon Trim
Round Rose
Door Cross Bore
2-1/8 Inches
Product Material
Zinc and steel, zinc dichromate plated for corrosion resistance
Recommended For
Commercial Real Estate, Retail, Multifamily and Hospitality
Standards
A156.2-2022, Series 4000 Grade 1 cylindrical locks, ICC A117.1 Accessible and Usable Buildings and Facilities, UL 10C and CAN/ULC-S104 listed
Function Description
Latch retracted by lever/knob from either side at all times
Front Size
1-1/8" x 2-1/4"
For Door Thickness
1-3/8" to 1-3/4"
Sub-Series
SchlageCom-PC10-BRW
Lever Style Family
Straight Lever
Latchbolt Type
Springlatch
Latch Corner
Square
Lever Length-Inches
4.50 Inches
Manufacturer Parent
Allegion
Product Type
Cylindrical Lock
Features
Suites with PM Series, PT Series, and ALX Series Grade 2 cylindrical locks
Product Projection
3.06 Inches
Strike Lip
1-3/16 Inch
Function Family
Passage/Hall/Closet
Product Overview
Performance Series Passage Latch Cylindrical Lock with Broadway Lever with 47272065 Latch and 47267101 Strike Bright Chrome Finish
