AD-200Standalone electronic lock

AD Series electronic locks from Schlage are designed to be modular and provide more options to choose from, more functionality in the lock and more compatibility with existing systems. Its patent-pending modular design allows the lock to be customized to fit the needs of an application now, and can change to meet future needs without removing it from the door.

Factory orderable options include choices of credential readers, chassis type, locking functions, power options, lever styles and finishes. It also offers a wide selection of features that can be configured in the field to customize your openings.

The AD-200 is a simple, economical solution if no access control system currently exists in facility, or for openings that don’t require the control of a networked solution. The AD-200 is easily upgradable to a networked lock if requirements change in the future.

On all AD Series standalone locks, Schlage has built in many of the incremental features needed in a networked system such as request-to-exit and -enter sensors, interior cover tamper guard, as well as the door position switch. This way, if the customer chooses to network this opening in the future, all the components will be there to make the transition an easy one.

Features and benefits:

• Security that’s more intelligent and convenient than traditional mechanical locking devices

• Audit trail reports that allow you to track usage and events

• Update users and access rights at the lock using the keypad or handheld device

• The ability to upgrade to a networked solution without removing the lock from the door

• Available in cylindrical, mortise, mortise deadbolt and exit trim

• Compatible with major brands of master key systems and exit devices

• Hardwired remote push button release capability

• Allows use of current aptiQ (Schlage) mobile credential utilizing NFC technology(1)

• ANSI/BHMA A156.25, ANSI/BHMA Grade 1, UL 294, UL 10C, FCC Part 15, ADA, RoHS, FL12400(2), FL1591(2), FL13013(2) and FL14482(2)

• (1) Refer to the Schlage/aptiQ mobile credential compatibility chart for a list of certified devices
• (2) Applies to cylindrical and mortise chassis only

Functions:

• Classroom/storeroom(2)

• Office(2)

• Privacy

• Apartment

Standard status signals:

• Lock/unlock status

• Mechanical key override

• Battery status

Specifications: Users:

• Up to 5000

Audits:

• Up to 5000

Credential verification time:

• < 1 second(1)

Visual/audible communications:

• Tri-colored LEDs and audible indicators (field configurable)

System interface:

• Handheld Device (HHD)

Power supply:

• 4AA, 8AA, 12 VDC or 24 VDC

Voltage range:

• 4 VDC to 26 VDC

Max current requirement:

• Up to 250 mA

Battery life:

• Up to 2 yrs with 4AA

Operating temperature - exterior:

• -31° to 151°F (-35° to 66°C)

Operating temperature - interior:

• 32° to 120°F (0° to 49°C) (battery)

Operating humidity:

• 0 - 100% non-condensing

Certifications:

• ANSI/BHMA A156.25, ANSI/BHMA Grade 1, UL 294, UL 10C, FCC Part 15, ADA, RoHS

Accessories:

• Handheld Device (HHD)

• (1) Verification time is dependent on size of user base
• (2)Classroom/storeroom and office function not available with mortise deadbolt option
