Schlage Residential JD60 625 J Series Polished Chrome Single Cylinder Deadbolt Lock
Item #: JD60 625 by Schlage Commercial
UPC #: 043156784226
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- Single Cylinder Deadbolt - Unlocked by Key from Outside or by Inside Thumbturn
- Applications: Residential single and multi family doors
- Backset: Universal deadolts fit 2-3/8" or 2-3/4" backset
- ANSI/BHMA A156.36 Grade 3
- Reversible Handing
- Certifications: Commercial Standard Certification:ANSI/BHMA A156.36-2010 Grade 3 Residential Standard Certification:ANSI/BHMA A156.40-2015 Grade CCC in Security, Durability and Finish
- Door thickness range: Door thickness range: 1-3/8" to 1-3/4" standard
- Includes All Mounting Hardware for Easy Installation
- Lifetime Mechanical & 5 Year Finish Warranty
- Keying: 5-pin, C keyway with 2 keys
- UL Listed: Available in boxpack for JD60, JD80 and JD81
Function
60-Single Cylinder Deadbolt
Handing
Reversible
Strike
Dual Radius Deadbolt and Full Lip
Backset
Dual Option-Round, Drive-In
Color Code
625/US26
Finish
Polished Chrome
Style
Round
Warranty
Lifetime Mechanical and 5 yr Finish
Handle Type
Touchless/None
Manufacturer Warranty
Lifetime mechanical and 5-year finish warranty
Assembled Depth (in.)
1
Assembled Height (in.)
2.5
Assembled Width (in.)
3.74
Backset size (in.)
Adjustable
Certifications and Listings
ANSI Certified, UL Listed
Commercial/Residential
Residential
Deadbolt strike width (in.)
1
Door Handing
Universal/Reversible
Door Locks & Knobs Product Type
Deadbolts
General Material
Metal
Hardware Finish Family
Chrome
Included
Hardware, Installation Instructions
Interior/Exterior
Interior/Exterior
Required door thickness (in.)
1 3/8 to 1 3/4
Security/ANSI Grade
ANSI Grade 3 (Good)
Features
Deadbolt Thrown or Retracted by Key From Outside or by Inside Turn Unit; Bolt Automatically Deadlocks When Fully Thrown; Dual Option Latches
Lock Type
Single Cylinder Deadbolt
Pack Size
1
Grade
ANSI/BHMA Grade 3
Keyway
Schlage C
Cylinder Type
Conventional Cylinder
Finish Description
Bright Polished Chrome
Keyblank Grouping
SCHR-C-5-1
Rose/Escutcheon Trim
Round Rose
Product Type
Auxiliary Lock
Projection
1.0000
Door Thickness
1-3/8" to 1-3/4"
Bore Size
2.1250
Product Height
3.15 Inches
Product Length
3.74 Inches
Included Components
Deadbolt; Roses; Latch; Strike; Mounting Hardware
Door Cross Bore
2.125 Inch
Keying Charges
Residential-Conventional
Product Material
Zinc
Box Length
3.7400
Box Width
3.7400
Box Height
3.1500
UNSPSC
46171500
Manufacturer Parent
Allegion
Door Edge Bore
1 Inch
Sub-Series
RL_Deadbolts_Schlage_Residential_16
ADA Compliant
No
Application
Residential Single- and Multi-Family Doors
Box Dimensions (L x W x H)
3.15x3.74x3.74
Function Family
Single Cylinder Deadbolt
Standards
ANSI/BHMA A156.36-2010
Finish Family
Polished Chrome
Cylinder Included
Yes
Strike Size
2-1/4" Full Lip
Alternate Part Number-1
135317
Latch Bolt Type
Deadbolt
Latch Bolt Faceplate Size
2-1/4" x 1"
Door Bore Size
2-1/8"
Lock Category
Deadbolts
Door Thickness Min
1-3/8"
Latch Bolt Face Type
Drive-In, Round Corner, Square Corner
Latch Bolt Throw
1"
Door Thickness Max
1-3/4"
Knob/Lever Style
Inside Thumbturn
With premium metal construction and plated keyways, Schlage mechanical and electronic deadbolts are made with durability in mind. Combine our wide range of unique finish and style options with our easy one-tool installation and you can give your door a stylish makeover in minutes.
Available Functions: JD60 - Single Cylinder Deadbolt Lock:- Deadbolt thrown or retracted by key from outside or by inside turn unit
- Bolt automatically deadlocks when fully thrown
- Deadbolt thrown or retracted from interior side only
- Deadbolt thrown or retracted from interior side only
- *Caution: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
- 16-068 - Dual Option (Round, Drive-in) - Standard
- 10-267 - One Radius Deadbolt Full Lip Strike (10-102)
& One Radius Deadbolt Strike (10-103) - Standard - 10-099 - Square Strike Plate & Strike Frame Reinforcer
- ANSI/BHMA A156.36-2010 Commercial Grade 3
- Dual Option: 1" x 2 1/4", 1/4" round faceplate, drive-in latch, 1" housing diameter, 1" throw
- 1" x 2 1/4" round corner and radius corner, full lip
- Adjustable for 2 3/8" or 2 3/4"
- 5-pin, C keyway, keyed alike (KA4)
- 1 3/8" - 1 3/4"
- Two brass cut keys per lock, 5-pin, C section
- Bright Brass (US3)
- Antique Brass (US5)
- Satin Nickel (US15)
- Antique Pewter (US15A)
- Matte Black (US19)
- Bright Chrome (US26)
- Satin Chrome (US26D)
- Satin Stainless Steel (US32D)
- Aged Bronze
- *Non-standard finishes are not available
- Full-color swatch examples available on inside Deadbolts tab
