Features
Manufacturer Parent
SDC Security
Finish Description
Black Anodized
Power Input
30VDC (Resistive) at 3A
Electrified Features
Tri-failsafe; Reliable pressure sense technology; Auto-sensing dual voltage
Sub-Series
EDT_Electronic_Devices_Trim_sdc_1
Device Type
Electromagnetic
Function Family
Part/Component
Standards
UL 294 Access Control System Units; CSFM Listed 3625-0324:105; UL 1034 Burglary-Resistant Electric Locking Mechanisms
Device Bar Projection
1-7/8"
Product Type
Access Control
Features
Quick and Quiet Operation; Heavy Duty Aluminum Extrusion; Temperature Tolerant; High Traffic Use; Narrow, Low-Profile
Current Draw
115 mA (Maximum); 20 mA (Continuous)
Switch Type
SPDT
Warranty
5 Year
Series
Parts/Accessories
Included Components
Power Transfer Loop; 10ft, Eight Conductor Cable
Finish Family
Black
Finish
335 Dull Black
Product Size
36"
Stile Type
Narrow or Wide Stile
Voltage
12/24VDC
Product Projection
1-7/8"
Wood Door Compatible
No
Temperature Range
0 to 150F
Power
115 mA Maximum 20 mA Continuous
Product Overview
SureExitSense Bar, Includes 10 Ft. Cable/Connector and PT-2U Armored Power Transfer Loop, Black Anodized Aluminum
Stable and Reliable Pressure Sense Technology Building codes essentially state that egress through access controlled doors must not require prior knowledge of operational requirements. Meeting this criteria, SDCÍs patented PSB560 Sure Exit Pressure Sense Bar is designed to release electromagnetic door locks for uninhibited egress. When slight pressure is applied to the non-latching bar, either of the two redundant solid state pressure sensors are actuated causing the electronics to immediately release the electromagnetic door locks.
Available in rim mount, mortise and surface vertical rod configurations.
