Seco 2505793 Milling Insert: 218.19-125T-T3-MD10, T350M, Solid Carbide TiCN
Item #: 2505793 by Seco
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Shape
Triangle
Cutting Edge Style
T-Land
Material Application
Steel
ANSI Code
218.19-125T-T3-MD10
Number of Cutting Edges
3
Standards
ISO
Insert Material
Solid Carbide
Series
218.19-125
Coating Process
CVD
Coating/Finish
TiCN
Corner Radius (Decimal Inch)
0.0315
Length (Decimal Inch - 4 Decimals)
0.3504
Manufacturers Catalog Number
218.19-125T-T3-MD10
Material Grade
Medium Grain
Primary Workpiece Material
Stainless Steel
Primary Workpiece Material Code
M
Thickness (Decimal Inch - 4 Decimals)
0.1563
Thickness (Inch)
5/32
Vendor Drop Ship
Y
Width (Decimal Inch - 4 Decimals)
0.3504
Coating Classification
CVD
Insert Holding Method
Screw
Maximum Depth of Cut (Decimal Inch)
0.0590
Multi-use Tool
Yes
Rake
Neutral
Secondary Workpiece Material
Steel
Insert Hand
Neutral
Inscribed Circle (Decimal Inch)
0.3504
Corner Radius (Inch)
1/32
Insert Shape
Trigon
Rake Angle
0
Chip Breaker
MD10
Secondary Workpiece Material Code
P
Insert Style
218.19
Insert Size Code
125T-T3
Hole Diameter (Decimal Inch)
0.1378
Relief Angle
12
Included Angle Degree
60
Manufacturer Grade
T350M
Inscribed Circle Range (Decimal Inch)
0.3500 to 0.4000
Single or Double Sided Insert
Single
Cutter Series Compatibility
R218.19-25
Length Range (Decimal Inch)
0.3200 to 0.4000
Thickness Range (Decimal Inch)
0.1500 to 0.1750
Convex Radius (Decimal Inch)
0.4921
Iso Code
218.19-125T-T3-MD10
Product Overview
Milling Insert: 218.19-125T-T3-MD10, T350M, Solid Carbide Coated, 0.156" Thick
