Seco 74018654 Turning Insert: CCMT21.52-F2 TP40, Solid Carbide TiC
Item #: 74018654 by Seco
See reviewsSee reviews
Use Code: SAVEBIG2025 for Extra 10% Off
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Cutting Edge Style
Honed
Number of Cutting Edges
2
Standards
ANSI
Included Angle
80degree
Insert Material
Carbide
Series
CCMT-F2
Coating Process
CVD
Coating/Finish
TiC
Corner Radius (Decimal Inch)
0.0315
Manufacturers Catalog Number
74018654
Material Grade
P40
Primary Workpiece Material
Steel
Primary Workpiece Material Code
P
UNSPSC Code
23242105
Vendor Drop Ship
N
Width (Decimal Inch - 4 Decimals)
0.2500in
Width (Inch)
1/4in
Coating Classification
CVD
Insert Holding Method
Screw
Insert Length (Decimal Inch)
0.2559
Insert Thickness (Decimal Inch)
0.0937
Insert Thickness (Inch)
3/32
Lead Angle
80degree
Maximum Depth of Cut (Decimal Inch)
0.2244
Multi-use Tool
Yes
Rake
Positive
Insert Hand
Neutral
Wiper Edge
No
Inscribed Circle (Decimal Inch)
0.2500
Corner Radius (Inch)
1/32
Insert Shape
Diamond 80
Clearance Code
C
Full Radius
No
Insert Shape Code
C
Chip Breaker
F2
Insert Style
CCMT
Insert Size Code
21.52
Tolerance Code
M
Hole Diameter (Decimal Inch)
0.1142
Relief Angle
7
Inscribed Circle (Inch)
1/4
Multi-Use Application
Boring
Manufacturer Grade
TP40
Length Range (Decimal Inch)
0.0000 - 0.3000
Inscribed Circle (mm)
6.35
Proprietary Coating Designation
Multilayer Coating
Iso Code
CCMT060208-F2
Product Overview
Turning Insert: CCMT21.52-F2 TP40, Solid Carbide TiC, TiCN & TiN Coated, 1/4" Inscribed Circle, 1/32" Corner Radius, 80 degree Diamond, Series CCMT
