Securitron PDB-1R PDB Interface Board
Item #: PDB-1R by SECURITRON
See reviewsSee reviews
Use Code: SAVEBIG2025 for Extra 10% Off
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Product Type
Access Control Part/Accessory
Series
Parts/Accessories
Alternate Part Number-1
159584
For Use With
AQD and AQS Power Supplies
ADA Compliant
No
Standards
UL 294 Listed; UL 603 Listed; ULC-S318 Listed; ULC-S533 Listed
Function Family
Part/Component
Features
Non Latching or Latching Mode; Form C Contacts Indicates Trigger Status; Normally ON and Normally OFF Output; Reverse Polarity Protected; Output LED’s Indicate Condition
Input Voltage
12/24VDC
Manufacturer Parent
Assa Abloy
Sub-Series
PDB-1R
Height
2.36
Length
5.71
Width
4.33
Product Overview
PDB-1R: Fire Trigger - Fire relay triggers power transfer in alarm situation
The PDB-1R uses an end-of-line resistor to trigger a form C contact in response to a fire system alarm condition In response to the trigger, the unit transfers power from the "Normally On" output. Additional triggered reactions include status feedback to firecontrol or annunciation systems, ground fault trigger and input trigger that latches until reset.
Product Features
Specifications
Certifications
The PDB-1R uses an end-of-line resistor to trigger a form C contact in response to a fire system alarm condition In response to the trigger, the unit transfers power from the "Normally On" output. Additional triggered reactions include status feedback to firecontrol or annunciation systems, ground fault trigger and input trigger that latches until reset.
Product Features
- Individual LED indicators show which output is powered
- Form C contact indicates trigger status
- Latching or non-latching mode
- Can provide ground supervision via jumper configuration
- Output triggers include: — Normally Open or Normally Closed with supervised End-of-Line resistor — Normally Closed override switch trigger input — Normally Closed uxiliary switch trigger input — Ground fault detection — Trigger status reporting
- MagnaCare lifetime replacement, No Fault Warranty
Specifications
- Dimensions: 3-3/4"H x 2-1/4"W x 13/16"D
- Electrical: 70mA used for relay control
Certifications
- UL 294 Recognized
- UL 603 Recognized
- ULC-S318-96 Recognized
