Single Cylinder Deadbolt from the 780 Series Satin Chrome

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Kwikset 780-26D Single Cylinder Deadbolt from the 780 Series Satin Chrome

Item #: 780-26D by Kwikset

UPC #: 883351761260

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • Add To A Keyed Knob Or Lever For Additional Security
  • Premium Security Features Including A 5-Pin Cylinder With Pick Resistant Pins.
  • Featuring SmartKey Security, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds
  • Features Adjustable Latch & Deadbolt To Fit All Standard Door Preparations
  • Ansi/Bhma Grade 2 Security
  • SmartKey Security is compatible with Kwikset (KW1) keyway
  • SmartKey cylinders feature a stainless steel side locking bar, racks and pins for increased strength and security
  • Patented side locking bar technology offers improved security by protecting against lock bumping, an attack technique used to defeat conventional pin and tumbler locks
  • Lifetime Mechanical And Finish Warranty
  • This single cylinder deadbolt can be locked or unlocked by a key on the outside or the turn piece on the inside

Height

2.625

Product Class

Residential

Theme

Traditional

Handing

Left, Reversible, Right

Backset

2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4"

Function

Single Cylinder

Shape

Round

Door Thickness

1-3/4 to 1-3/8"

ADA

Yes

ANSI Certification

A156.5

BHMA Certification

Grade 2

Cross Bore

1-1/2", 2-1/8"

Cylinder

6 Pin

Edge Bore

1"

Panic Proof

No

Series

Signature Series

Latch Faceplate

Drive-In, Round Corner, Square Corner

Removable Core

Yes

Projection

2.15625

Collection

780-Series

Finish

Satin Chrome

Dimensions

2-1/2 in Dia x 15/16 in L

Application

For right or left hand doors

Warranty

Lifetime

Cylinder Type

5-Pin

Faceplate Size

1 x 2-1/4"

Strike Size

1-1/4 x 3-5/8"

Backset Size

2-3/8 2-3/4"

Keyway type

SmartKey

Number of Cylinders

1

Throw Length

1"

Nomenclature

780-26D LOCK SNGL DEADBOLT

Re-Key Technology

Smartkey

Product Overview
LOCK SNGL CYL DEADBOLT 780-26D
Specifications:

Suitable for: 1-3/8 to 1-3/4 in Thick Doors

Operated by key outside and thumb turn inside. Door Prep: 2-1/8 in or 1-1/2 in crossbore; 1 in edge bore; 1 x 2-1/4 in latch face. Door Thickness: 1-3/8 in to 1-3/4 in standard. 1-7/8 in to 2-1/4 in optional. Cylinder: 5-pin SmartKey cylinder. Faceplate: 1 x 2-1/4 in. Strike: 1-1/4 x 3-5/8 in. Bolt: 1 in throw, stainless steel. Handing: Reversible for right or left hand doors. ANSI/BHMA: Grade 2. ADA: Interior turn piece meets 4.13.9 ADA requirements. Deadbolts with SmartKey in (denoted SMT) feature allow, in 3 steps, locks to be re-keyed to a spare set of keys. When the spare keys are done being used, the lock can be re-keyed back to the original set of keys; can continually be re-keyed.
