30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Constructed from solid brass with an antique brass finish, this heavy-duty surface bolt is designed for lasting use in door security.
- Measures 12-1/2" in total length and 5/8" in width, featuring a 1-1/4" projection and a 1-1/4" diameter knob for easy operation.
- Designed for surface mounting on the inside of doors, this bolt provides 109 lb rod resistance for added door security applications.
- Features a 12" x 5/8" rod dimension with a 1-1/16" rod extension, ensuring compatibility with standard door security requirements.
- Includes 2 guides with a 1-1/2" guide width, providing stable and smooth operation for the barrel slide bolt latch mechanism.
- Supplied with universal, mortise, and angle strikes to accommodate various door frame setups and installation configurations.
- Comes with matching Phillips head screws for installation and is backed by a limited 1 year mechanical and 1 year finish warranty.
Length
12-1/2
Dimensions
Diameter: 0.625 inches
CatchType
Barrel Slide Bolt Latch
Finish
US5
Box Qty
10 pc
Rod Dimensions
12"
Material
Solid Brass
Projection
1-1/4
Width
5/8
Function
Surface Bolt
Size
12" Length
Includes
2 Guides
Pack Size
1
Screws Included
Yes, With Matching Phillips Head Screws
Other Specifications
Rod Dimensions: 12"x 5/8" Knob Diameter: 1-1/4" Guide Width: 1-1/2" Rod Extention:1-1/16"
Available Strikes
Universal Mortise & Angle Strike
Product Type
Surface Bolt
Package Height
1.25"
Package Length
12"
Package Width
1"
Item Weight
1 lbs
No of inners
1
Series
Bolts
Finish code
US5
Hazardous Material
No
Manufacturer Warranty
Limited 1 Year Mechanical and 1 Year Finish Warranty
Dimension
12"
Options
Heavy-Duty
Mounting Method
Surface
Product Material
Brass
Substrate Type
Brass
Product Size
12"
Map Policy
Yes
Manufacturer Parent
Deltana
Finish Description
Antique Brass
Sub-Series
Deltana-12SB
Function Family
Door Accessory
Features
Designed to be Mounted in the Inside of a Door to Offer Extra Security
Color Code
609/US5
Product Length
12 Inches
Included Components
Strikes
Finish Family
Antique Brass
Product Overview
The 12" Surface Bolt is a heavy-duty door accessory designed for surface mounting on the inside of a door to provide additional security. Constructed from solid brass, this surface bolt features a 12-1/2" length and a 5/8" width. The rod measures 12" x 5/8" with a 1-1/16" rod extension. It includes two guides with a 1-1/2" guide width and a 1-1/4" projection. The knob diameter is 1-1/4". This barrel slide bolt latch is supplied with three types of strikes: universal, mortise, and angle strike, along with matching Phillips head screws for installation. It offers a 109 lb rod resistance and is finished in antique brass. This product has an item weight of 1 lbs and is backed by a limited 1 year mechanical and 1 year finish warranty. The surface bolt is designed for smooth operation and is suitable for various door security applications.
