TAYLOR UPGRADE V3.0 TO V4.0 Upgrade to Phoenix V4.0

Item #: UPGRADE V3.0 TO V4.0 by TAYLOR TECHNOLOGIES INC

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Alternate Part Number-1

171089

Product Overview

TAYLOR TECHNOLOGIES PHOENIX v4.0 Software

Phoenix E-Lock Tool: eliminates the need to drill most keypad equipped safes in the event of a lock out due to lost combination, lock malfunction or keypad failure. Simply remove the existing keypad, plug the lock and/or keypad cable into the Phoenix and select the appropriate opening or diagnostic feature from the on-screen menu. In minutes the Phoenix will have the safe open with no drilling, no repairs to the safe and no replacement of the lock.

PHOENIX VERSION HISTORY:

  • 1st Generation:
    • Version 1.5 - S&G 6120 Resets.
    • Version 1.6 - Keypad Testing, Lock Diagnostics & Programming.
    • Version 2.0 - S&G 6123 Resets.
    • Version 2.2 - Improved S&G 6120/6123 Resets.
  • 2nd Generation:
    • Version 3.0 - “Black” Junction Box, Gen2 32-bit CPU, LaGard Basic/33E Resets.
    • Version 3.1 - S&G Titan & Spartan Resets.
    • Version 3.2 - “Red” Junction Box, Sentry Resets, LG Basic Plus Resets, LaGard 3045 Programmer, LaGard Internal Battery Resets.
  • 3rd Generation:
    • Version 4.0- Touchscreen, Rechargeable, AMSEC ESL-10/20 Resets, LaGard 39E Resets, Ionic Spiking.

    FEATURES:

  • Lost Code Recovery / Lock Reset (via keypad):
    • AMSEC: ESL-10?, ESL-20.
    • Sargent & Greenleaf: 6120 ('98 - '13), 6121, 6123 ('98 - '13), Biometric, Titan PivotBolt, Spartan PivotBolt, Titan D-Drive, & Spartan D-Drive.
    • Lagard: Basic/Basic Plus (through 2019), LGBasic (green board), LGBasic II (blue board through 2019), LGCombo (all), ComboGard 33E (all), SafeGard 3650 (all), ComboGard Pro 39E, 3801, 3802, 4200, 3040, 3260, 3765, 3740 (all), & 2441 Mechanical Redundant (all).
    • Sentry Safe: SF Series?.
  • Lost Code Recovery / Lock Reset (via BAT port on lock case):
    • Lagard: AuditGard 66E, LPAudit, LGAudit, & 6441 Mechanical Redundant.
  • Lock Malfunction Diagnostics (Automated):
    • Sargent & Greenleaf: 6120, 6123, Titan, Spartan, Z/02, Z/03, RotaryBolt, PivotBolt, & D-Drive.
    • Lagard: LGBasic, LGBasic II, LGBasic Plus, LGCombo, Combogard 33E, Combogard Pro 39E, Auditgard 66E, LPAudit, & LGAudit.
    • LP Locks: EL-20 Rotobolt, EL-25 Rotobolt, DB-20 Straightbolt, & DB-25 Straightbolt.
    • NL Locks.
    • SecuRam: SafeLogic series.
    • AMSEC: ESL/10 & ESL/20.
    • Sentry Safe?: SF Series.
  • Keypad Testing:
    • Sargent & Greenleaf: Two Battery, Single Battery EZ-View, Low Profile, & D-Drive.
    • Lagard: 3710, 3715, 3125, 3000, 3035, 4715, 3750, & 3750-K.
    • LP Locks.
    • NL Locks.
    • SecuRam: SafeLogic series.
    • Amsec: ESL/10, ESL/20.
  • Integrated IONIC Lock Spiking
    • AMSEC: ESL-5 & ESL-15.
    • LP/NL.
    • Tecnosicurezza.
    • LaGard: Deadbolt (Motor) & Swingbolt (Motor).
  • Integrated Electronic Safe Lock Quick Reference (2018):
    • Lock identification, programming procedures and drilling info right at your fingertips.
  • Programmable Service Routines:
    • Quickly save and re-use routines to automate common service tasks such as setting up new locks and user codes.
  • Lock Conditioning and Repair:
    • Repair common drive nut issues with S&G 6120/23 series locks.
    • Clean & condition 6120/23 threads to reduce cross-threading risk.
  • RED Multi-Lock Junction Box:
    • Directly connect locks from overa half dozen different manufacturers without any special adapters or dongles and with zero splicing or damage to lock and keypad cables.
    • Safely connect to internally powered locks.
  • Integrated JumpBox:
    • Portable electronic safe lock power boost for overcoming binding or stalled solenoids and motors.
  • Integrated “UNO” Universal Keypad:
    • Use the Phoenix as a universal emergency and servicing keypad for S&G, Lagard, LP, NL, Amsec, SecuRam and Sentry SF Series.
  • Keypad/Lock Communication Signal Conditioning:
    • Lock not accepting codes? Simply plug the keypad and lock into the Junction Box and the Phoenix will automatically intercept and repair any faulty signals between the lock and keypad allowing the safe to be opened without drilling or parts replacement.
  • Automatic Lock Identification & Feature ID:
    • Just connect the lock and let the Phoenix automatically identify the exact make, model and version.
    • Determine if a lock is deadlocking, solenoid blocking or motor driven from outside the safe.
  • Automated Lock Programming and Setup:
    • Eliminates time consuming, hard to remember keypad programming procedures.
  • Time Delay and Dual Control Bypass (LaGard 33E / 3650).
  • Integrated LaGard 3045 Handheld Programmer.
  • Quick and Easy Software Updates over USB:
    • Update your Phoenix to the latest software release over the included micro-USB cable in seconds using our exclusive Phoenix Loader software.
  • Emergency One-Time-Code (OTC) for rapid safe opening.
  • Batch Resets:
    • Quickly handle jobs with multiple lock outs at a single location.

    FINISHES:

  • » N/A
