Alarm Lock DL3200 US10B Trilogy Electronic Digital Lock Oil Rubbed Bronze Finish
Item #: DL3200 US10B by Alarm Lock
See reviewsSee reviews
In Stock
$1,010.53
/eachSAVE UP TO 101.05
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business day
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Retrofits Most Cylindrical Locksets and Digital Locks
- 2000 user codes (3-6 digits) Multilevel security - Master; manager; supervisor; basic users
- Multi-Level User Codes and One-Time Service Codes
- Program at keypad or with PC-and/or data-transfer module
- Free Passage, Group or Total Lock-Out Codes
- 40,000 event audit trail logs with time-/date-stamp of access by user; create PC reports or at hand-held wireless printer
- 500 scheduled lock/unlock events
- Typical 100,000 Cycle Battery Life
- Non-Handed
- Quick passage mode (without being in program mode)
- Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)
- 5AA Battery operated; 80,000 cycles, typical
Finish
Oil Rubbed Bronze
Function
Double Cylinder
Series
DL
Design
Digital Keypad
Strike
1-1/8" x 2-3/4" T-Strike, 1-1/4" x 4-7/8" ASA Strike
Product Class
Commercial
Backset
2-3/8", 2-3/4"
ADA
Yes
Panic Proof
Yes
Manufacturer Warranty
2 Year, 2 Year Limited
Number of Codes
2000
Usage Monitoring
No
Width
3.25
Power Source
Battery
maximum users
2000
Remote Access
No
Handle Style
Lever
temporary access
Yes
UL Listed
Yes
Projection
1.75
Smartphone Enabled
No
Fire Rated
3 Hours {A}
Approved for Commercial Use
Yes
Height
8.25
auto-lock capable
Yes
input type
Keypad
Theme
Modern
BHMA Certification
Grade 1
Door Thickness
1-5/8 In. to 1-7/8 In.
Handle Material
Metal
Lit Keypad
No
ANSI Certification
A115
Configuration
Electronic
Cylinder
6 Pin Schlage C
Material
Zinc
ANSI Approved
Yes
Cross Bore
2-1/8"
Cylinder Included
Yes
Handle Width
3.25
Handle Projection
2.5625
Handle Length
4.75
Handing
Left Hand Reverse
Package Height
7.125"
Package Length
9.25"
Package Volume
576.6796875
Package Width
8.75"
Number of users
2000
Keypad Type
Electronic
Latch Backset Dimension
2-3/4 In.
Lock Platform
Cylindrical Lock
Package Qty
1
Programmer
Optional
Reader Technology
Keypad Only
Software
Optional
Special Marks
Fire rated 3 Hours {A}
Strike Type
T-Standard and ASA
Base Material
Bronze
Grade
Grade 1
Power
Battery Pack
Color
Dark Oxidized Satin Bronze Oil Rubbed
Color Code
613/US10B
Cylinder Type
Conventional Cylinder
Alternate Part Number-1
176998
Product Overview
Pushbutton Cylindrical Door Lock, 2000 Users, 40,000 Event Audit Trail, Weatherproof, Straight Lever, Oil Rubbed Bronze
High Capacity Audit Trail Lock. Enhanced version of the original DL3000. 2000 user codes (3-6 digits). Multilevel security - Master; manager; supervisor; basic users. Program at keypad or with PC-and/or data-transfer module. 40,000 event audit trail logs with time-/date-stamp of access by user; create PC reports or at hand-held wireless printer. 150 scheduled lock/unlock events. Quick passage mode (without being in program mode). Weatherproof -31 Deg. to +151 Deg. F (-35 Deg. to +66 Deg. C).
Enhanced version of the original DL3000
High Capacity Audit Trail Lock. Enhanced version of the original DL3000. 2000 user codes (3-6 digits). Multilevel security - Master; manager; supervisor; basic users. Program at keypad or with PC-and/or data-transfer module. 40,000 event audit trail logs with time-/date-stamp of access by user; create PC reports or at hand-held wireless printer. 150 scheduled lock/unlock events. Quick passage mode (without being in program mode).
