Widia 4170458 Turning Insert: CNMG431ML, Carbide TiN
Item #: 4170458 by Widia
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Width (Inch)
1/2
Insert Material
Carbide
Insert Thickness (Decimal Inch)
0.1875
Vendor Drop Ship
N
Maximum Depth of Cut (Decimal Inch)
0.1580
Iso Code
CNMG120404ML
Width (Decimal Inch - 4 Decimals)
0.5
Secondary Workpiece Material
Cast Iron
Relief Angle
0
Cutting Edge Style
Honed
Clearance Code
N
Rake
Negative
Material Grade
P25
Insert Length (Decimal Inch)
0.5077
Insert Holding Method
Clamp
Coating/Finish
TiN
Rake Angle
10
UNSPSC Code
23242105
Corner Radius (Inch)
1/64
Insert Style
CNMG
Manufacturers Catalog Number
4170458
Insert Hand
Neutral
Proprietary Coating Designation
Multilayer Coating
Manufacturer Grade
WP25CT
Inscribed Circle (Inch)
1/2
Secondary Workpiece Material Code
K
Standards
ANSI
Inscribed Circle (Decimal Inch)
0.5000
Coating Process
MTCVD
Primary Workpiece Material
Steel
Insert Shape Code
C
Corner Radius (Decimal Inch)
0.0156
Insert Thickness (Inch)
3/16
Hole Diameter (Decimal Inch)
0.2031
Chip Breaker
ML
Multi-Use Application
Turning
Length Range (Decimal Inch)
0.5000 - 0.6000
Multi-use Tool
No
Full Radius
No
Tolerance Code
M
Coating Classification
CVD
Wiper Edge
No
Insert Size Code
431
Included Angle
80
Number of Cutting Edges
8
Series
CNMG-ML
Insert Shape
Rhombic
Primary Workpiece Material Code
P
Product Overview
Turning Insert: CNMG431ML, Carbide TiN, TiCN, Al2O3 & ZrCN Coated, Neutral, 0.5077" Long, 1/2" Inscribed Circle, 0.0157" Corner Radius, 80 degree Diamond, Series CNMG
