YG-1 22000182 Turning Insert: CNMG120404-UG YG3020, Solid Carbide Al2O3
Item #: 22000182 by YG-1
See reviewsSee reviews
Use Code: SAVEBIG2025 for Extra 10% Off
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Cutting Edge Style
Chamfered
Number of Cutting Edges
4
Standards
ANSI
Included Angle
80
Insert Material
Carbide
Series
CNMG
Side Clearance
Negative
Coating Process
CVD
Coating/Finish
Al2O3
Corner Radius (Decimal Inch)
0.0156
Manufacturers Catalog Number
22000182
Material Grade
P15
Primary Workpiece Material
Steel
Primary Workpiece Material Code
P
UNSPSC Code
23242105
Vendor Drop Ship
N
Width (Decimal Inch - 4 Decimals)
0.5000
Width (Inch)
1/2
Coating Classification
CVD
Insert Holding Method
Clamp
Insert Length (Decimal Inch)
0.5080
Insert Thickness (Decimal Inch)
0.1875
Insert Thickness (Inch)
3/16
Maximum Depth of Cut (Decimal Inch)
0.1180
Multi-use Tool
No
Rake
Negative
Insert Hand
Neutral
Wiper Edge
No
Inscribed Circle (Decimal Inch)
0.5000
Corner Radius (Inch)
1/64
Insert Shape
C - Diamond (Rhombic) 80-Deg
Clearance Code
N
Rake Angle
-20
Full Radius
No
Insert Shape Code
C
Chip Breaker
UG
Insert Style
CNMG
Insert Size Code
431
Tolerance Code
M
Inscribed Circle (Inch)
1/2
Multi-Use Application
Turning
Manufacturer Grade
YG3020
ISO Size Code
120404
Length Range (Decimal Inch)
0.5000 - 0.6000
ANSI Size Code
431
ISO Insert Code
CNMG120404
Proprietary Coating Designation
Multilayer Coating
Iso Code
CNMG120404UG
ANSI Insert Code
CNMG431
Product Overview
Turning Insert: CNMG120404-UG YG3020, Solid Carbide TiCN & Al2O3 Coated, 0.472" Long, 1/2" Inscribed Circle, 1/64" Corner Radius, Series CNMG
