ZOELLER 506538SSClick To Copy Shallow Well Jet Pump System, 3/4 HP, Stainless Steel, 16 Gallon Tank

This shallow well jet pump system, identified by model 506538SS, is designed for residential water supply applications, suitable for homes, cottages, and farms. The system includes a 3/4 HP pump and a 16 US gallon pressure tank, both constructed from stainless steel to prevent rust contamination and ensure potable, rust-free water. It operates on dual voltage 115V/230V at 60Hz and features a totally enclosed fan-cooled (TEFC) motor with thermal and overload protection. The system incorporates a bladder-style pressure tank with a synthetic butyl rubber bladder, which eliminates water-air and water-tank contact, contributing to extended reliability. It offers easy priming and comes pre-assembled for straightforward installation. The pump has a maximum vertical suction lift of 25 feet, a capacity of up to 900 US gallons per hour (GPH), and is equipped with a 1-inch NPT discharge. It delivers a maximum pressure of 65 PSI and includes a pre-assembled 30/50 PSI pressure switch. While originally listed under Zoeller, the model 506538SS is consistently associated with BURCAM brand products.
