Sargent 351C EN 351 Door Closer Cover, Aluminum Painted
Item #: 351C EN by Sargent
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Color
Aluminum Painted
Color Code
689/US28
Package Qty
1
Finish
Aluminum Painted
Function
Cover
Finish Description
Aluminum Painted
Product Type
Door Control Part/Accessory
For Use With
351 Series
Hand
Non-Handed
Handing
Non-Handed
ADA Compliant
No
Finish Family
Aluminum
Product Material
Plastic
Function Family
Part/Component
Features
High Impact; Non-Corrosive
Manufacturer Parent
Assa Abloy
Sub-Series
PA_Door_Control_Parts_sargent_37
Featuring heavy-duty construction for superior strength and wear resistance, the 351 Series Powerglide® Door Closer is ideally suited for highly trafficked environments like schools, healthcare facilities, and office and commercial buildings. With a full complement of arm types and front-facing valves, the 351 series can be easily installed and maintained—for interior and exterior applications.
General Information: Closer Spring Adjustment:- Effects the entire cycle of the door closer movement
- Used to size closer for application requirements
- Determines the amount of force with which the door closes and the amount of force required to open the door
- Adjustable to compensate for door size and draft conditions
- At approximately 70° of the open cycle, the Backcheck Valve begins to slow the door’s motion
- Prevents the door from slamming into the door’s stop
- Valve is used to control the intensity of the Backcheck
- Note: A Positive stop is required; Backcheck cannot be used as a stop
- Controls how fast the door closes to approximately 8" from the closed position, along with the closer spring
- Controls the speed of the door during the final 8" of door swing
- The force the door closes with is controlled by the closer spring
- Note: This adjustment is critical for door latching
- Certified ANSI/BHMA A156.4 Grade 1
- UL 10C listed for positive pressure fire test
- UL /cUL listed for use on fire rated doors
- 25 year limited warranty
- User friendly versatile mounting applications permit standard, top jamb, parallel and track installations
- Self sticking templates supplied for most applications
- Adjustable spring power allows 351 closers a size range of 1 through 6. They are adjusted to size 3 before leaving the factory
- One door closer body for all applications. All 351 are non-handed
- Meets ADA requirements in all applications, except Push Side Track application (except track)
- High impact non-corrosive plastic covers with two machine screws standard, metal covers and lead lined are optional
- All weather fluid allows closer to operate effectively in extreme temperatures without readjustment
- 1-1/2" diameter piston for superior door control
- Standard pressure relief valves for both opening and closing cycles protect the door & frame from damage caused by abuse
- Heat treated full closed rack and pinion provide control from the full open position
- Heavy duty one piece die cast aluminum silicon alloy body with 14% silicon provides superior strength and wear resistance
- 1/2" arm engagement over a 7/16 square spindle ensures a wear-resistant tight joint
- Machine Screws and self tapping screws provided for closer and arm
- Brass body low sensitivity control valves offer separate regulating for door speed, latching, backcheck and optional delayed action
- All valves are controlled by an 1/8" allen wrench to discourage tampering and are captivated to prevent removing valves from the body and damaging door closer
- Adjustable backcheck (standard) protects the door and hardware from damage during the opening cycle
- Adjustable delayed action (optional) permits easy access for physically impaired individuals
- Valves are captivated to prevent accidental removal
- Interchangeable forged steel arms
- Standard and parallel arms
- Push and pull track arms (including double egress)
- Heavy duty forged steel arms are finely finished and interchangeable between SARGENT 351, 1431 and 281 Series
