Adams Rite 4550L-01-119 4550 MS Deadlock Lever, Black Painted
Item #: 4550L-01-119 by Adams Rite
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Housing: Aluminum casting is 1-3/8” wide x 7-1/2” long x 1” deep.
- MS Deadlock Lever
- Lever: 3” long aluminum with end-return design offers comfortable grip to lock or unlock.
- Easily Unlocks and MS Deadlock with Three Pounds of Downward Force
- Indicator: Words “LOCKED” in red letters or “OPEN” in black letters appear on white background when lock is thrown or retracted. Indicator is driven by lock bolt itself.
- Spring-Loaded Lever Locks and Reloads with Upward Motion
- Indicator Signals Lock Status
- Stop Clearance: Lever housing projects 11/16” forward of cylinder backset centerline. Depending on height of door stop and width of door/jamb gap, it may be necessary to modify the stop to clear the housing. For fin type stops, this is easily accomplished. Hollow stops may preclude use of lever.
- Compatible Deadlocks: Any MS® pivoted bolt deadlock including “Schoolhouse” versions can be fitted with the 4550 including MS1850S, MS1950, MS1837, etc. Derivative units such as 1870, 1870HM, or 1877 flushbolts (bolt into threshold) are also operable by the 4550 lever. Not compatible with MS+1890 Deadlock/Latch or with 7/8” backset locks.
- Warranted Free From Defects In Workmanship And Materials Under Normal Use And Service
- Options: Available in three finishes to match anodized aluminum finishes. Can be ordered for left or right hand door, but is easily reconfigured in the field to accommodate either door swing.
- Standard Package: Individually boxed with installation instructions, mounting screws, and drive pins for both single point and threshold bolt-equipped locks. Shipping weight: 1 lb.
Package Length
8.375"
Lever/Knob Design
Flat Lever w/Return
Base Material
VARIES
Rose/Escutcheon Design
Rectangle with Indicator
Product Length
7.2344"
BAA Qualified
Yes
Origin
USA
Color Code
119
Package Width
5"
Screws
Machine
Package Height
2.5"
Package Qty
1
Product Height
7-15/64 Inch
Hand
Left Hand/Left Hand Reverse
Product Width
1-13/32 Inch
For Use With
MS1850S, MS1950
Color
Satin Black Ritecoat Paint
Package Volume
104.6875
Thickness
1-3/4" - 2"
Finish
Black Painted
Handing
Reversible
Function
Deadlock Lever
Design
End-Return Handle
Series
4500 Series
Finish Description
Black
Product Type
Lock Part/Accessory
Warranty
1 Year From Date of Purchase.
Aluminium Bottle Contents
Swinging
ProductType
Manual
Door Thickness
1-3/4" to 2"
ADA Compliant
No
Corner Type
Square
Finish Family
Black
Included Components
Mounting Hardware and Drive Pins for Both Single Point and Threshold Bolt-Equipped Locks
Spring Type
Lever Return
Product Material
Cast Aluminum (Housing); Aluminum (Lever)
Lever Size
3-5/32 Inch
Function Family
Part/Component
Product Projection
2-15/32 Inch
Indicator Configuration
"Locked" in Red Letters/"Open" in Green Letters
Features
Rotate Lever Downward 90° to Unlock. When Released, Lever Returns to Horizontal. Rotate Lever Upward 90° to Relock; Key Operation From Outside is Not Affected. Clutching Action Prevents Damage to Internal Components
Manufacturer Parent
Assa Abloy
Escutcheon Thickness
1-1/16 Inch
Escutcheon Size
1-13/32" x 7-15/64"
Sub-Series
PA_Locks_Parts_adams_rite_29
Product Overview
LH or LHR, 1-3/4" to 2" Door Thickness, 119 To Match 335 Black Anodized
