83" 700 Pin and Barrel Continuous Hinge, Satin Stainless Steel

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

IVES 700 83IN US32D 83" 700 Pin and Barrel Continuous Hinge, Satin Stainless Steel

Item #: 700 83IN US32D by IVES

UPC #: 044074996845

See reviewsSee reviews
See reviews summary

$550.95

/each
SAVE UP TO 55.09
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Color

Satin Stainless Steel

Restrictions

Oversized

Package Qty

1

Hinge Type

Continuous Full Mortise

Color Code

630/US32D

Base Material

Stainless Steel

Finish

Satin Stainless Steel

Finish Description

Satin Stainless Steel

Product Type

Hinge/Pivot

Hinge Size

83 Inch

Series

700 Series

For Use With

1-3/4" Doors

Function

Continuous Hinge

Maximum Door Width

48 Inch

Bearing Type

Split

Product Length

83 Inch

ADA Compliant

No

Finish Family

Stainless Steel

Product Material

Stainless steel

Standards

Exceeds Grade 1 ANSI/BHMA 156.26; UL10C listed

Fastener Size

10 X 1/2" Self Drilling, Self Tapping Screws; 10 X 1" Wood Screws

Function Family

Hinge/Pivot

Manufacturer Parent

Allegion

Sub-Series

700-83IN-32D

Product Overview
700 full mortise pin and barrel continuous hinge
  • 1/4" diameter pin with nylon self-lubricating, medical grade split bearing
  • For doors weighing up to 300 pounds without reinforcing. 600 pounds with reinforcing
  • 1/8" Insert recommended for 1-3/4" doors
  • 48" Maximum door width
  • Non handed for custom cut lengths
  • Bevel or square edge door

Certifications
  • Certified to ANSI/BHMA A156.26
  • UL10C certified

Standard mounting hardware
  • #10 x 1/2" Self Drilling, Self Tapping Screws
  • #10 x 1" Wood Screws

Material
  • 14 Gauge Type 304 stainless steel
