Arrow RK11-BD-10B-R60-R70-CS RK Series Cylindrical Knob Lock Oil Rubbed Dark Bronze
Item #: RK11-BD-10B-R60-R70-CS by Arrow
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Finish
Oil Rubbed Dark Bronze
Backset
2-3/8 Inch, 1 x 2-1/4 Inch, Square Corner
Keyway
Schlage C
Cylinder Type
Conventional Cylinder
Finish Description
Oil Rubbed Dark Bronze
Latch Number
R70
Knob style
BD-Ball
Product Type
Cylindrical Lock
Series
RK Series
Strike Number
R60
Grade
ANSI/BHMA Grade 2
Application
Multi Family Housing Markets; Light Commercial
Function
11-Entrance/Office
Handle Type
Knob
Rose Diameter
2-1/2 Inch
Strike
T-Strike, 1-1/8 Inch x 2-3/4 Inch, 1-1/4 Inch Lip, Sq Corner
Warranty
5 Year Mechanical
Color Code
613/US10B
Latch Throw
1/2 Inch
Latch Type
Deadlatch
Strike Type
T-Strike
Finish Family
Dark Bronze
Strike Size
1-1/8" x 2-3/4"
Cylinder Material
Cold Rolled Steel
Rose/Escutcheon Trim
Round Rose
Standards
ANSI A156.2; UL Listed
Cylinder Type Used
Conventional
Front Size
1" x 2-1/4"
Function Family
Entry/Entrance/Office
Latch bolt size
7/8 Inch
Strike Lip
1-1/4 Inch
Product Projection
2-3/4 Inch
Trim Material
Wrought Brass(Rose)
Features
Guarded Latchbolt on All Locking Functions
Manufacturer Parent
Assa Abloy
Latch Corner
Square
Knob/Lever Size
2-1/8 Inch
Latch Bolt Material
Brass
Knob Style Family
Ball Knob
Sub-Series
RK11-BD-10B-R60-R70-CS
Product Overview
Standard Duty Cylindrical Knob Lock - Entrance Function - Ball (BD) Knob - R60 T-Strike (1-1/8" x 2-3/4", 1-1/4" Lip, Square Corner) - R70 Dead Latch (1", Square Corner, UL, 2-3/8" Backset) - 10B Oil-Rubbed Dark Bronze Finish - Keyed Different, CS Keyway
