Arrow RL02-SR-US3-R62-R73Click To Copy RL Series Cylindrical Lever Lock Bright Polished Brass

RL SeriesCylindrical Locksets

The RL Series cylindrical locksets are an economical value for a variety of application. Perfect for multi-family housing markets, as well as light commercial applications. This product is now available in either standard or IC core versions and both are supplied with removable thru-bolts.*

Certification:

• The RL Series has been designed to meet the requirements of ANSI, A156.2, Series 4000, Grade 2 UL Listed for use on 3 hour, A label single swinging doors. RL Levers conform to ADA requirements.

ADA/Americans with Disabilities Act: Acceptable Door Hardware: Section 4.13.9:

• Handles, pulls, latches and other operating devices on accessible doors shall have a shape that is easy to grasp with one hand and does not require grasping, tight pinching or twisting of the wrist to operate. Lever operated mechanisms, push-type mechanisms and "U" shaped handles are acceptable designs.

Features: Construction:

• Cold rolled steel with zinc dichromate finish for corrosion resistance. Requires standard 2-1/8" (53.97mm) bore through door.

Backset:

• 2-3/8" (60.31mm) or 2-3/4" (69.85mm)

Door Thickness:

• Fits 1-3/8" (34.93mm) to 1-3/4" (44.45mm)

Latch:

• Brass 1/2" (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions

Latch Front:

• 1" x 2-1/4" (25.40mm x 57.15mm) for 2-3/8" backset (60.32.mm) or 1-1/8" x 2-1/4" for 2-3/4" (69.85mm) backset.

Exposed Trim:

• RL Levers are pressure cast zinc measuring 4-3/4" (120.65mm) in length. RL Roses are wrought brass 3-3/8" (85.73mm) diameter. Total projection from face of door is 2-1/2" (63.5mm).

Strike:

• 4-7/8" ANSI (123.83mm), 2-3/4" (69.85mm) T strike, or 2-1/4" (57.15mm) full lip strike.

Cylinder:

• Conventional - Solid brass 6 pin. Arrow "A" keyway standard. C keyway optional.
• Interchangeable Core – Lockset prepared to use with 6 or 7 pin interchangeable core. Will accept cores manufactured by Arrow, Best, Falcon, Medeco Keymark, ASSA, and others.*

Keys:

• 2 brass keys

Handing:

• Non-handed

Finishes:

• US3, US4, US10, US10B, US26 and US26D

Thru-bolts:

• Removable thru-bolts standard on RL Series

Packaging:

• 10 per case

Warranty:

• 5 year mechanical warranty

• *Product will accept other manufacturers' cylinders but cannot be ordered with the product.
